House Small Maglev Wind Power Generator Rooftop stainless steel
House Small Maglev Wind Power Generator Rooftop stainless steel
Specifications
Price :
Negotiable
Parking / Service Brake: manufacturer :
Automatic method: pitch control (controller speed detection, when exceeding the set speed when the pitch control deceleration action) + short-circuit braking.
Brand Name :
Honor Eco
Model Number :
HECO-3000
Tower Type (lattice, tubular steel, cement pipe） :
tubular steel structure
Place of Origin :
Shenzhen, China
MOQ :
1
controller :
Off-grid or On Grid
Supply Ability :
100 sets
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Delivery Time :
25 working days
Voltage range of Grid-side converter :
180-260Vac one phase
Packaging Details :
Plywood
Certification :
CE ISO9001 IEC
Frequency range of Grid-side converter :
47.00-52.00 Hz
Generator :
Three phase AC permanent magnet generator
Description


House Small Maglev Wind Power Generator Rooftop stainless steel




1. Brief to 3kw wind turbine


HECO-3000 Vertical Axis Maglev Wind Turbine is a breakthrough in wind power technology. It’s Honor Eco who made magnetic levitation technology used in wind turbine for the first time. This creates a milestone and fulfills important breakthrough in the history of small and medium wind turbine development. The maglev technology improves the efficiency of wind power 35% compared to traditional horizontal axis wind turbine. The innovative wind generators have been widely used for Telecoms Base Receiver Station (BTS) as well as residential and commercial applications.



1, No Vibration-Means you can mount anywhere including on your house roof

2, No Noisy-Means quiet enjoyment of living

3, No Frication-Means the equipment lasts longer due to no wear & tear

4, Low start-up wind speed-Means higher average power output

5, No rust - use Aluminum Alloy material, technical treatment by DACROMAT

6, No fade- after anti-oxidation treatment

7, Strong adaptability-means can be used for land, beaches, weak offshore wind

Regional power, lighting etc.



2. Maglev Wind Power Generator Feature:

  • Magnetic levitation technology
  • Independent of the direction of the wind
  • Startup at low wind speed of 1m/s
  • Higher efficiency compared to traditional HAWT
  • Works even in turbulence
  • Visually pleasing appearance
  • Turbine construction is resistant to gale 60m/s (132MPH)
  • Robustness and adaptation to all possible environmental conditions thanks to material of aluminum alloy or stainless steel
  • Design life: at least 20 years
  • Noise: Tested by China National Machinery Quality Inspection Centre at 12m/s: <40db


3. Specifications


Items HECO3000-Ⅰ HECO3000-Ⅱ
Rated power 3000W 3000W

Dimension

(Height/Diameter)

 3530/Ø3600 Ø4160/4570
Weight 415KG 680 kg
Blade material Aluminum Alloy Aluminum Alloy
Blade quantity 3 3
Swept area ㎡ 7.02 7.72
Min starting wind speed 1.5m/s 1.5m/s
Cut-in wind speed 3.5m/s 3.5m/s
Rated wind speed 13m/s 13m/s
Cut-off wind speed 15m/s 15m/s
Survival wind speed 60m/s 60m/s
Generator type AC,3Phases AC,3Phases
Controller Output Voltage 48V 96V
Controller Braking System 3-phase short circuit by NFB brake 3-phase short circuit by NFB brake
Ambient Temperature -40～50 ℃ -40～50 ℃
Noise Tested by China National Machinery Quality Inspection Centre at 12m/s: <40db



4. Application :


The practical appication of the Maglev Wind Power Generator as below:

1) Power supply for ships

2) Electricity for agriculture and fishery

3) Landscape education of wind energy and electricity

4) Wind-hydraulic generation system

5) Public electricity supply for building

6) Romote area

7) Independent house

8) Correspondence base

9) Street light

10) Electricity supply for community

11) Traffic signals

12) Independent smart power island
