Aluminum Alloy Maglev Eolic Wind Turbine Without Motor Brushes

Rated Power:300W
Wind wheel diameter:1.23M/1.09M
Weight:25KG
Blade Material: Aluminum Alloy
The number of blade:3
Minimum wind speed start:1m/s
Minimum power wind speed:2m/s
Rated wind speed:12m/s
Maximum cut off wind speed:15m/s
Resistant to wind speed limit:65m/s
The type of Generator: Three-phase AC maglev wind turbine
Controllor output voltage:24V /12V
Controllor output current:<20Amp
Controllor brake system: Over speed automatic Three-phase

Short-circuit braking Normal operating temperature:-40～50 ℃

Design:​

• Gear-free design: No need to replace worn-out or broken teeth

• Brushless: No motor brushes that are high failure items and need

replacements regularly

• Bearing-free design: No need to lubricate or to replace worn-out bearings

• Floating magnet design: reduces rotational resistance to enhance electricity

generation and extend turbine life
• No yaw or furling mechanism required: allows for peak power output at any wind speed

• No cogging torque for cutting-in at low wind speed

• Direct-drive: Extends product life

• Blades can start rotating at a mere wind velocity of 2.2 mph (1 m/s)

• Space-saving, aerodynamic airframe

• Heavy duty, industrial-quality construction

Installatio:

• Easy Installation: System can be assembled in under an hour without any welding

• Single or multiple unit connections for greater energy generation

• Easy connection with PV systems

Environment:

​• Produces zero emissions

• Synergy with Solar and Geothermal systems
• Dual colors alert bats and birds of obstacle (animal-friendly)

Control:

• Intelligent control system with active protective functions to

automatically lower rotational speed during strong winds
• Remote monitoring available to monitor and assess data and equipment performance
