Nichrome NiCr6015 Alloy Wire High Resistivity 0.05-10.0mm
Nichrome NiCr6015 Alloy Wire High Resistivity 0.05-10.0mm
Nichrome NiCr6015 Alloy Wire High Resistivity 0.05-10.0mm
Nichrome NiCr6015 Alloy Wire High Resistivity 0.05-10.0mm
Nichrome NiCr6015 Alloy Wire High Resistivity 0.05-10.0mm
Nichrome NiCr6015 Alloy Wire High Resistivity 0.05-10.0mm
Specifications
MOQ :
20kg
Price :
40
Payment Terms :
T/T,L/C,D/P,D/A,Western Union,MoneyGram
Supply Ability :
500ton/year
Delivery Time :
25days
Packaging Details :
Case
Corrosion Resistance :
Excellent
Resistivity :
0.35
Specification :
0.05-10.0mm
Port :
Shanghai,China
Insulation :
Bare
Resisivity :
1.11
Oem Service :
: Accept
Packing :
Case
Description

Different Size Nichrome Alloy Wire NiCr6015/MWS-675

1.About Nichrome NiCr6015 wire
Nichrome alloy NiCr6015 characterized by high resistivity, good oxidation resistance ,good form stability and good ductility and excellent weldability. It is suitable for use at temperatures up to 1150°C.

2.NiCr6015 has many other Grade name:
Ni60Cr15,Chromel C, N6, HAI-NiCr 60, Tophet C, Resistohm 60, Cronifer II,Electroloy, Nichrome, Alloy C, Alloy 675, MWS-675, Stablohm 675,NiCrC

Performance material
Cr10Ni90
Cr20Ni80
Cr30Ni70
Cr15Ni60
Cr20Ni35
Cr20Ni30
Composition
Ni
90
Rest
Rest
55.0~61.0
34.0~37.0
30.0~34.0
Cr
10
20.0~23.0
28.0~31.0
15.0~18.0
18.0~21.0
18.0~21.0
Fe
≤1.0
≤1.0
Rest
Rest
Rest
Maximum temperatureºC
1300
1200
1250
1150
1100
1100
Meltiing point ºC
1400
1400
1380
1390
1390
1390
Density g/cm3
8.7
8.4
8.1
8.2
7.9
7.9
Resistivity at 20ºC((μΩ·m)
1.09±0.05
1.18±0.05
1.12±0.05
1.00±0.05
1.04±0.05
Elongation at rupture
≥20
≥20
≥20
≥20
≥20
≥20
Specific heat
J/g.ºC
0.44
0.461
0.494
0.5
0.5
Thermal conductivity
KJ/m.hºC
60.3
45.2
45.2
43.8
43.8
Coefficient of lines expansion
a×10-6/
(20~1000ºC)
18
17
17
19
19
Micrographic structure
Austenite
Austenite
Austenite
Austenite
Austenite
Magnetic properties
Non-magnetic
Non-magnetic
Non-magnetic
Weak magnetic
Weak magnetic


6.Series of Nichrome Wire
Nickel chrome alloys: Ni80Cr20, Ni70Cr30, Ni60Cr15, Ni35Cr20, Ni30Cr20, Cr25Ni20, pure nickel Ni200 and Ni201

7.All shape of Nichrome
Wire, ribbon( flat wire ), strip, bar, plate, tube

8.size of NiCr6015
Wire: 0.018mm-10mm
Ribbon: 0.05*0.2mm-2.0*6.0mm
Strip: 0.5*5.0mm-5.0*250mm
Bar: 10-100mm

9.Main Advantage and Application

(1). Nickel-chromium, nickel-chromium alloy with high and stable resistance, corrosion resistance, surface oxidation resistance is good, a better under high temperature and seismic strength, good ductility, good workability and weldability.

(2).NiCr6015 widely used in househole, such as: grills, toaster ovens, air heater, clothes dryer, hand heaters and so on.
NiCr6015 widely used in the heating element which made for industrial heating furnace, such as tempering furnace and drying furnace.
