Nickel Iron Alloy Capillary Tube Alloy 52 with 0.3mm-8.0mm OD Bright Surface in Soft Hard or Middle Condition
Nickel Iron Alloy Capillary Tube Alloy 52 with 0.3mm-8.0mm OD Bright Surface in Soft Hard or Middle Condition
Specifications
Brand Name :
TANKII
Model Number :
TK41152
Certification :
ISO9001
Place of Origin :
Shanghai, China
MOQ :
1KG
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 Tons per month
Delivery Time :
7-20 days
Packaging Details :
Wooden Case
Material :
nickel Iron alloy tubes
Name :
TK41152
sample :
accepted small order
OD :
0.3mm-8.0mm
WT :
0.015mm Min.
Condition :
Soft / Hard / Middle
surface :
Bright
ID :
0.10 mm Min.
Length :
0.25 mm Min.
standard :
GB/ASTM/JIS/BIS/DIN
Alloy Type :
Expansion Alloy
Process :
cold rolled
Description

Precison alloy TK41152 Nife52/Nilo 52/Feni52 Capillary Tubes Alloy 52/ASTM F30 Nickel Iron Alloy Pipe for sealing fibreglass

TK41152 The iron-nickel constant expansion alloy is a series of constant expansion alloys that can be matched with soft glass and ceramics with different expansion coefficients in a given temperature range by adjusting the nickel content. Its expansion coefficient and Curie point increase with the increase in nickel content. The combination gold is a sealing structure material widely used in the electric vacuum industry.
The alloy is mainly used for sealing with soft lead glass and small electronic tube leads. Zh
In the application, the selected sealing material should match the expansion coefficient of the alloy. The grain size should be controlled during heat treatment to ensure that the material has good deep-drawing properties. When using forged and rolled materials, the air tightness of the materials should be strictly checked.
Normal composition%

Ni 50.5~52.5 Fe Bal. Co - Si ≤0.3
Mo - Cu - Cr - Mn ≤0.8
C ≤0.05 P ≤0.02 S ≤0.02

Typical Physical properties

Density (g/cm3) 8.25
Electrical resistivity at 20ºC(ohm.mm2/m) 0.43
Temperature factor of resistivity(20ºC~200ºC)X10-6/ºC 9.8~11
Thermal conductivity, λ/ W/(m*ºC) 16.7
Curie point Tc/ ºC 520
Elastic Modulus, E/ Gpa 144


Coefficient of expansion

θ/ºC α1/10-6ºC-1 θ/ºC α1/10-6ºC-1
20~-60 20~100 10.3
20~-40 20~200 10.4
20~-20 20~300 10.2
20~-0 20~350 10.3
20~50 20~400 10.3
20~100 20~450 10.3
20~150 20~500 10.3
20~200 20~600 10.8

Typical Mechanical properties

Tensile Strength Elongation
Mpa %
641 14
689 9
731 8
The heat treatment process
Annealing for stress relief Heated to 530~550ºC and hold 1~2 h. Cold down
annealing In order to eliminate hardening, which be bring out in cold-rolled, cold drawing process. Annealing needs heated to 830~880ºC in vacuum,hold 30 min.
The stabilization process
In protective media and heated to 830 ºC, hold 20min. ~ 1h, quench
Due to the stress generated by quenching, heated to 315ºC,hold 1~4h.
Precautions
Can not be hardened by heat treatment,
Surface treatment can be sandblasting, polishing or pickling.
Alloy can be used 25% hydrochloric acid pickling solution at 70 ºC to clear oxidized surface
