Specifications
Brand Name :
Tankii
Model Number :
Nickel-Cromium Wire 3070
Certification :
ISO9001
Place of Origin :
China
MOQ :
10kg
Price :
20-25USD/Kg
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
500tons/year
Delivery Time :
7-45 days
Packaging Details :
case
Round Wire Diameter :
0.018mm-10mm
Nichrome Ribbon Width :
5~0.5mm
Nichrome Ribbon Thickness :
0.01-2mm
Description

Nickel-Cromium Wire 3070 Nickel Wire With High Quality

Nichrome Round Wire: Diameter 0.018mm~10mm

Nichrome Ribbon: Width 5-0.5mm, thickness 0.01-2mm
Grade: Ni80Cr20, Ni70/30, Ni60Cr15, Ni60Cr23, Ni35Cr20Fe

Nichrome's metallurgical structure confers them a very good plasticity when cold.
ASTM B603, DIN 17470, JIS C2520, GB/T1234.

Our advantage: High quality,short delivery time,small MOQ.
Characteristics: Stable performance; Anti-oxidation; Corrosion resistance; High temperature stability; Excellent coil-forming ability; Uniform and beautiful surface condition without spots.
Usage:Resistance heating elements;Material in metallurgy;Household appliances;Mechanical manufacturing and other industries.

Chemical Composition and Main Properties of Nichrome
Properties Grade NiCr 80/20 NiCr 70/30 NiCr 60/15 NiCr 35/20 NiCr 30/20
Main Chemical Composition Ni Balance Balance 55.0-61.0 34.0-37.0 30.0-34.0
Cr 20.0-23.0 28.0-31.0 15.0-18.0 18.0-21.0 18.0-21.0
Fe ≤ 1.0 ≤ 1.0 Balance Balance Balance
Max Continuous Service Temperature (oC) 1200 1250 1150 1100 1100
Resisivity 20oC
(Ω mm2/m)		 1.09 1.18 1.12 1.04 1.04
Density
(g/cm3)		 8.4 8.1 8.2 7.9 7.9
Thermal Conductivity
(KJ/m@ h@ oC)		 60.3 45.2 45.2 43.8 43.8
Coefficient of Thermal Expansion (α × 10-6/oC) 18 17 17 19 19
Melting Point ( oC) 1400 1380 1390 1390 1390
Elongation (%) > 20 > 20 > 20 > 20 > 20
Micrographic Structure austenite austenite austenite austenite austenite
Magnetic Property nonmagnetic nonmagnetic nonmagnetic Weak magnetic Weak magnetic
