0.18mm 0.25mm Ni80cr20 Nichrom Wire For Nickel Mesh
0.18mm 0.25mm Ni80cr20 Nichrom Wire For Nickel Mesh
0.18mm 0.25mm Ni80cr20 Nichrom Wire For Nickel Mesh
0.18mm 0.25mm Ni80cr20 Nichrom Wire For Nickel Mesh
0.18mm 0.25mm Ni80cr20 Nichrom Wire For Nickel Mesh
0.18mm 0.25mm Ni80cr20 Nichrom Wire For Nickel Mesh
Specifications
Brand Name :
Tankii
Model Number :
Ni80cr20
Certification :
ISO9001
Place of Origin :
China
MOQ :
10kg
Price :
20-30USD/KG
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
5000kg/Month
Delivery Time :
10-15days
Packaging Details :
case
TypeType :
Nickel Wire
Chemical Composition :
Ni 76%
Range of Application :
Resistor, Heater,Chemical
The Highest Use Temperature :
1400
Elongation :
>=20%
Specification :
0.01-8.0mm
Description
0.18mm 0.25mm Ni80Cr20 Nichrom Wire For Nickel Mesh


Description

Chemical Composition and Propertes:
Propertes/Grade NiCr 80/20 NiCr 70/30 NiCr 60/15
Main Chemical Composition(%) Ni Bal. Bal. 55.0-61.0
Cr 20.0-23.0 28.0-31.0 15.0-18.0
Fe ≤ 1.0 ≤ 1.0 Bal.
Max Working Temperature(ºC) 1200 1250 1150
Resistivity at 20ºC(μ Ω · m) 1.09 1.18 1.12
Density(g/cm3) 8.4 8.1 8.2
Thermal Conductivity(KJ/m· h· ºC) 60.3 45.2 45.2
Coefficient of Thermal Expansion(α × 10-6/ºC) 18 17 17
Melting Point(ºC) 1400 1380 1390
Elongation(%) > 20 > 20 > 20
Micrographic Structure austenite austenite austenite
Magnetic Property nonmagnetic nonmagnetic nonmagnetic

Propertes/Grade NiCr 35/20 NiCr 30/20 Karma Evanohm
Main Chemical
Composition(%)		 Ni 34.0-37.0 30.0-34.0 Bal Bal
Cr 18.0-21.0 18.0-21.0 19.0-21.5 19.0-21.5
Fe Bal. Bal. 2.0-3.0 -
Max Working Temperature(ºC) 1100 1100 300 1400
Resistivity at 20ºC
(μ Ω · m)		 1.04 1.04 1.33 1.33
Density(g/cm3) 7.9 7.9 8.1 8.1
Thermal Conductivity
(KJ/m· h· ºC)		 43.8 43.8 46 46
Coefficient of Thermal
Expansion(α × 10-6/ºC)		 19 19 - -
Melting Point(ºC) 1390 1390 1400 1400
Elongation(%) > 20 > 20 10-20 10-20
Micrographic Structure austenite austenite austenite austenite
Magnetic Property nonmagnetic nonmagnetic nonmagnetic nonmagnetic
Chemical Composition Nickel 80%, Chrome 20%
Condition Bright/Acid white/Oxidied Color
Diameter 0.018mm~1.6mm in spool, 1.5mm-8mm packing in coil, 8~60mm in rod
Nichrome Round Wire Diameter 0.018mm~10mm
Nichrome Ribbon Width 5~0.5mm, thickness 0.01-2mm
Nichrome Strip Width 450mm~1mm, thickness 0.001m~7mm
Diameter 1.5mm-8mm packing in coil, 8~60mm in rod
Grade Ni80Cr20, Ni70/30, Ni60Cr15, Ni60Cr23, Ni35Cr20Fe,
Ni30Cr20 Ni80, Ni70,Ni60, Ni40,
Advantage The metallurgical structure of nichrome
confers them a very good plasticity when cold.
Characteristics Stable performance; Anti-oxidation; Corrosion resistance;
High temperature stability; Excellent coilforming ability;
Uniform and beautiful surface condition without spots.
Usage Resistance heating elements;Material in metallurgy,
Household appliances;Mechanical manufacturing and
other industries.
Resistance Wires
RW30 W.Nr 1.4864 Nickel 37%, Chrome 18%, Iron 45%
RW41 UNS N07041 Nickel 50%, Chrome 19%, Cobalt 11%, Molybdenum 10%, Titanium 3%
RW45 W.Nr 2.0842 Nickel 45%, Copper 55%
RW60 W.Nr 2.4867 Nickel 60%, Chrome 16%, Iron 24%
RW60 UNS NO6004 Nickel 60%, Chrome 16%, Iron 24%
RW80 W.Nr 2.4869 Nickel 80%, Chrome 20%
RW80 UNS NO6003 Nickel 80%, Chrome 20%
RW125 W.Nr 1.4725 Iron BAL, Chrome 19%, Aluminium 3%
RW145 W.Nr 1.4767 Iron BAL, Chrome 20%, Aluminium 5%
RW155
Iron BAL, Chrome 27%, Aluminium 7%, Molybdenum 2%
