Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
Specifications
Brand Name :
TANKII
Model Number :
Nickel Plated Copper Wire
Certification :
ISO SGS
Place of Origin :
China
MOQ :
Negotiable
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 Tons per Month
Delivery Time :
7-12 work days
Packaging Details :
wooden case / Carton
Material :
Silver Plated Copper Alloy Wire
Diameter :
0.05mm
Surface :
Bright
Color :
Silver
Coating Thickness（um） :
0.3-5.0
Name :
Silver Plated Copper Wire
Description

Enameled Tin / Nikcel / Silver Plated Copper Alloy Ribbon/ Flat Wire for cable

Silver Plated Copper Alloy Wire

Product standard: refer to JB / T 3135-2011, ASTM B289-99 or according to customer requirements

Item Diameter(mm)
0.016 0.02 0.025 0.03 0.04 0.05
Tolerance(mm) ±0.001 ±0.001 ±0.002 ±0.002 ±0.002 ±0.002
Conductivity(%) ≧70
Elongation(%) ≧6 ≧10
Tensile Strength(MPa) /
Coating Thickness(um) ≧0.3
Appearance No scratches, oil stains, exposed copper, oxidation, etc.
Packing 3 inch, 5 inch, etc.
Remark According to customers’ requirements

Soft Wire

Silver Plated Copper Alloy Wire-Hard Wire

Item Diameter(mm)
0.016 0.02 0.025 0.03 0.04 0.05
Tolerance(mm) ±0.001 ±0.001 ±0.002 ±0.002 ±0.002 ±0.002
Conductivity(%) ≧70
Elongation(%) ≤4
Tensile Strength(MPa) ≧700
Coating Thickness(um) ≧0.2
Appearance No scratches, oil stains, exposed copper, oxidation, etc.
Packing 3 inch, 5 inch, etc.
Remark According to customers’ requirements

Silver Plated Copper Alloy Stranded Wire

Item Diameter(mm)
7/0.016 7/0.02 7/0.025 7/0.03 7/0.04 7/0.05
Tolerance(mm) ±0.001 ±0.001 ±0.002 ±0.002 ±0.002 ±0.002
Conductivity(Ωmm2/m) ≧70
Strand 7
Direction of Twist S(right)
Elongation(%) ≤4(Hard)
≧5(Soft)
Tensile Strength(MPa) ≧700(Hard)
/(Soft)
Coating Thickness(um) ≧0.2
Appearance No scratches, oil stains, exposed copper, oxidation, etc.
Packing Type 200
Remark According to customers’ requirements

Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
