0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire
0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire
0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire
0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire
0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire
0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire
Specifications
Model Number :
CuNi44
Packaging Details :
Cardboard packaging+wooden box
Delivery Time :
7-20days
Resistivity :
0.49 μΩ·m
Features :
Ultra Fine Diameter, Stable Resistance, Low TCR, Excellent Insulation, Good Flexibility
Payment Terms :
T/T
Applications :
Medical Devices, Precision Electronics, Micro Sensors, Miniature Heating Elements, Electronic Components, Precision Instruments
Price :
negotiation
Certification :
ISO9001
MOQ :
1kg
Brand Name :
TANKII
Supply Ability :
500kg/month
Surface :
Enameled
Condition :
Soft Annealed
Material :
Enameled Copper Nickel Alloy
Bare Wire Diameter :
0.01-1 mm
Insulated Wire Diameter :
Customized According to Enamel Grade
Place of Origin :
China
Alloy Grade :
CuNi44 / Constantan
Shape :
Round Wire
Enamel Type :
Polyurethane / Polyester / Polyimide / Customized
Description
Product Description
0.01mm Ultra Fine Enameled Constantan CuNi44 Wire for Micro Sensor and Medical Equipment

Product Description

0.01mm ultra fine enameled Constantan wire is manufactured from CuNi44 (6J40) copper nickel resistance alloy with excellent electrical stability, low temperature coefficient of resistance and superior flexibility. The ultra-small diameter design allows the wire to be used in compact and precision applications where space and reliability are critical.

Different enamel insulation options including PE, PEI, PI and PAI are available to meet various temperature, mechanical and chemical resistance requirements. The wire provides stable performance during long-term operation and is suitable for micro sensors, medical equipment, precision electronic components, miniature resistors and advanced measurement systems.

Customized diameter, insulation thickness, spool size and packaging solutions are available according to customer requirements.

Tpye of Insulation:

  • Polyester resistance wire , class 130
  • Modified polyester resistance wire , class 155
  • Polyesterimide resistance wire , class 180
  • Polyester (imide) coated with polyamide-imide resistance wire , class 200
  • Polyimide resistance wire , class 220
Constantan 6J40 New Constantan Manganin Manganin Manganin
6J11 6J12 6J8 6J13
Main Chemical Elements % Mn 1~2 10.5~12.5 11~13 8~10 11~13
Ni 39~41 - 2~3 - 2~5
Cu REST REST REST REST REST
Al2.5~4.5 Fe1.0~1.6 Si1~2
Temperature Range for Components 5~500 5~500 5~45 10~80 10~80
Density 8.88 8 8.44 8.7 8.4
g/cm3
Resistivity 0.48 0.49 0.47 0.35 0.44
μΩ.m,20 ±0.03 ±0.03 ±0.03 ±0.05 ±0.04
Extensibility ≥15 ≥15 ≥15 ≥15 ≥15
%Φ0.5
Resistance -40~+40 -80~+80 -3~+20 -5~+10 0~+40
Temperature
Quotiety
α,10 -6 /
Thermoelectromotive 45 2 1 2 2
force to Copper
μv/(0~100)

Tpye of Bare Wire

main

property

type


Cuni1

CuNI2

CuNI6

CuNI10

CuNi19

CuNi23

CuNi30

CuNi34

CuNI44

main

chemical

composition

Ni

1

2

6

10

19

23

30

34

44


MN

/

/

/

/

0.5

0.5

1.0

1.0

1.0


CU

rest

rest

rest

rest

rest

rest

rest

rest

rest

max

working

temperature


/

200

220

250

300

300

350

350

400

density

g/cm3


8.9

8.9

8.9

8.9

8.9

8.9

8.9

8.9

8.9

resistivity

at 20 °c


0.03
± 10%

0.05
±10%

0.1
±10%

0.15
±10%

0.25
±5%

0.3
±5%

0.35
±5%

0.40
±5%

0.49
±5%

temperature

coefficient of

resistance


<100

<120

<60

<50

<25

<16

<10

-0

<-6

tensile

strength mpa


>210

>220

>250

>290

>340

>350

>400

>400

>420

elongation


≥25

≥25

≥25

≥25

≥25

≥25

≥25

≥25

≥25

melting

point °c


1085

1090

1095

1100

1135

1150

1170

1180

1280

coefficient of

conductivity


145

130

92

59

38

33

27

25

23
0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire
0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire
0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire


0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire0.01mm Enameled CuNi44 Constantan Ultra Fine Micro Wire
