Bright Annealed Alloy Nikrothal 80 Wire For Electric Heating Resistance
Bright Annealed Alloy Nikrothal 80 Wire For Electric Heating Resistance
Bright Annealed Alloy Nikrothal 80 Wire For Electric Heating Resistance
Bright Annealed Alloy Nikrothal 80 Wire For Electric Heating Resistance
Bright Annealed Alloy Nikrothal 80 Wire For Electric Heating Resistance
Bright Annealed Alloy Nikrothal 80 Wire For Electric Heating Resistance
Bright Annealed Alloy Nikrothal 80 Wire For Electric Heating Resistance
Bright Annealed Alloy Nikrothal 80 Wire For Electric Heating Resistance
Specifications
Brand Name :
TANKII
Model Number :
Cr20Ni80
Certification :
DIN, ASTM, JIS ROHS
Place of Origin :
Jiangsu, China
MOQ :
10KG
Price :
30-80USD
Payment Terms :
T/T, L/C, , Western Union
Supply Ability :
50 tons per month
Delivery Time :
5-10 work days
Packaging Details :
spool ,coil, carton, wood box, or as clients' requirement
Grade :
NiCr8020, Chromel A, Nikrothal 80, NCHW1,N8, Cronix 80, Alloy A, Stablohm 650, MWS-650
Application :
furnace heating wire/household appliances
Elongation (≥ %) :
20
Resistance (μω.m) :
1.09
Ultimate strength (≥ mpa) :
750 N/mm²
Type :
Nickel Chrome Alloy
Surface :
Bright Annealed
Shape :
round wire
Material :
Nichrome
Condition :
soft annealed
Standard :
ASTM B162, GB/1234 2012, GB/T 2054-2013, ASTM ASME, ASME SB162
Density :
8.4
Feature :
high temperature strength
Description

Factory Supplier Nichrome Alloy Nichrothal 80 Wire Electric Heating Resistance Alloy Wire

Quick Details

Resistance heating wire includes pure nickel, chromel alloy, Fe-Cr-Al alloy and copper nickel alloy. Resistance heating wire is produced by smelting, steel rolling, forging, annealing, drawing, surface treatment, resistance control test, etc. It is widely used for making heating equipment like industrial furnace, civil heating appliance, various electrical resistors and locomotive braking resistor.

  • Name: Heating resistance wire
  • Type: Ni-Cr wire, pure Nickel, Chromel alloy, Fe-Cr-Al alloy, Copper nickel alloy, etc.
  • Color: bright, oxidized
  • Package: Carton or wooden case as demanded
  • Application: making heating equipment like industrial furnace, civil heating appliance, various electrical resistors and locomotive braking resistor
  • Place of Origin: Jiangsu, China (Mainland)
  • Eco-friendly: Yes
  • MOQ: 5kgs
  • Certificate: ISO,CQC
  • Making sample time: all type in stock
  • Trade term: FOB, EXW, CIF, CFR
  • Payment term: T/T, Western Union, L/C

Specification for wires

Diameter(mm) Tolerance(mm) Diameter(mm) Tolerance(mm)
0.03-0.05 ±0.005 >0.50-1.00 ±0.02
>0.05-0.10 ±0.006 >1.00-3.00 ±0.03
>0.10-0.20 ±0.008 >3.00-6.00 ±0.04
>0.20-0.30 ±0.010 >6.00-8.00 ±0.05
>0.30-0.50 ±0.015 >8.00-12.0 ±0.4

Specification for Strips/Sheets

Thickness(mm) Tolerance(mm) Width(mm) Tolerance(mm)
0.05-0.10 ±0.010 5.00-10.0 ±0.2
>0.10-0.20 ±0.015 >10.0-20.0 ±0.2
>0.20-0.50 ±0.020 >20.0-30.0 ±0.2
>0.50-1.00 ±0.030 >30.0-50.0 ±0.3
>1.00-1.80 ±0.040 >50.0-90.0 ±0.3
>1.80-2.50 ±0.050 >90.0-120.0 ±0.5
>2.50-3.50 ±0.060 >120.0-250.0 ±0.6

Alloy Type Diameter
(mm)		 Resistivity
(μΩm)(20°C)		 Tensile
Strength
(N/mm²)		 Elongation(%) Bending
Times		 Max.Continuous
Service
Temperature(°C)		 Working Life
(hours)
Cr20Ni80 <0.50 1.09±0.05 850-950 >20 >9 1200 >20000
0.50-3.0 1.13±0.05 850-950 >20 >9 1200 >20000
>3.0 1.14±0.05 850-950 >20 >9 1200 >20000
Cr30Ni70 <0.50 1.18±0.05 850-950 >20 >9 1250 >20000
≥0.50 1.20±0.05 850-950 >20 >9 1250 >20000
Cr15Ni60 <0.50 1.12±0.05 850-950 >20 >9 1125 >20000
≥0.50 1.15±0.05 850-950 >20 >9 1125 >20000
Cr20Ni35 <0.50 1.04±0.05 850-950 >20 >9 1100 >18000
≥0.50 1.06±0.05 850-950 >20 >9 1100 >18000
1Cr13Al4 0.03-12.0 1.25±0.08 588-735 >16 >6 950 >10000
0Cr15Al5 1.25±0.08 588-735 >16 >6 1000 >10000
0Cr25Al5 1.42±0.07 634-784 >12 >5 1300 >8000
0Cr23Al5 1.35±0.06 634-784 >12 >5 1250 >8000
0Cr21Al6 1.42±0.07 634-784 >12 >5 1300 >8000
1Cr20Al3 1.23±0.06 634-784 >12 >5 1100 >8000
0Cr21Al6Nb 1.45±0.07 634-784 >12 >5 1350 >8000
0Cr27Al7Mo2 0.03-12.0 1.53±0.07 686-784 >12 >5 1400

>8000

Bright Annealed Alloy Nikrothal 80 Wire For Electric Heating ResistanceBright Annealed Alloy Nikrothal 80 Wire For Electric Heating Resistance
