CuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ Strip
CuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ Strip
CuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ Strip
CuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ Strip
CuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ Strip
CuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ Strip
CuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ Strip
CuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ Strip
Specifications
Brand Name :
TANKII
Model Number :
CuNi23
Certification :
ISO9001:2015
Place of Origin :
Shanghai, China
MOQ :
Negotiable
Price :
To negotiate
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
20+TON+MONTH
Delivery Time :
7-15 days
Packaging Details :
Spool, Coil, Carton, Wooden case with Plastic Film According to Client's Requirements
Chemical Composition :
Cu Bal, Ni 23%
Surface Treatment :
Bright Annealed
Type :
Resistance Alloy
Color :
Silver
Other alloy :
CuNi44, CuNi40, CuNi30....
Description

CuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ Strip

Introduction:

CuNi23Mn is a copper-nickel alloy (CuNi alloy) with medium resistivity for medium-low temperature resistances. The alloy is suitable for use at temperatures up to 400°C (750°F). It is very malleable and has a good resistance to corrosion until temperatures of 400°C. Ideal applications areas are all types of resistances used at low temperature, typically used in heating cables, fuses, resistors and various types of controllers.

Physical Data

Density 8.9 g/cm3

Specific Heat 0.37(J/kg 20°C)

Electrical Resistivity 0.03×10-6ohm.m

Melting Point 1150°C

Maximum Operating Temperature 400°C

Coefficient of linear expansion (coeff 10-6/°C) 15.7 from 20 to 1000°C

Main Mechanical Properties:

Typical Physical properties

Density (g/cm3) 8.9
Electrical resistivity at 20℃ (mm2/m) 0.35
Temperature factor of resistivity(20℃~600℃)X10-5/℃ <10
Conductivity coefficient at 20℃ (WmK) 27
EMF vs Cu(μV/℃ )(0~100℃ ) -37

Coefficient of thermal expansion
Temperature Thermal Expansion x10-6/K
20 ℃- 400℃ 17

Specific heat capacity
Temperature 20℃
J/gK 0.390

Melting point (℃) 1170
Max continuous operating temperature in air (℃) 350
Magnetic properties non-magnetic

CuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ StripCuNi23 CuNi Alloy Good Corrosion Resistance Flat Annealed Ribbon/ Strip
