Ni200/Ni201/Nickel200/ Nickel 201 Purity Over 99.6% Pure Nickel Strip For Electric Bicycle
Ni200/Ni201/Nickel200/ Nickel 201 Purity Over 99.6% Pure Nickel Strip For Electric Bicycle
Ni200/Ni201/Nickel200/ Nickel 201 Purity Over 99.6% Pure Nickel Strip For Electric Bicycle
Ni200/Ni201/Nickel200/ Nickel 201 Purity Over 99.6% Pure Nickel Strip For Electric Bicycle
Ni200/Ni201/Nickel200/ Nickel 201 Purity Over 99.6% Pure Nickel Strip For Electric Bicycle
Ni200/Ni201/Nickel200/ Nickel 201 Purity Over 99.6% Pure Nickel Strip For Electric Bicycle
Ni200/Ni201/Nickel200/ Nickel 201 Purity Over 99.6% Pure Nickel Strip For Electric Bicycle
Ni200/Ni201/Nickel200/ Nickel 201 Purity Over 99.6% Pure Nickel Strip For Electric Bicycle
Specifications
Brand Name :
TANKII
Model Number :
Nickel strip
Certification :
SGS
Place of Origin :
Shanghai China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 Tons per Month
Delivery Time :
7-12 work days
Packaging Details :
Wooden Case,
Material :
Nickel foil strip
Purity :
99.6%
Width :
300 mm Max.
Thickness :
10um-1.5mm
Color :
Silver gray
Name :
Ni foil
Description

Ni200/Ni201/Nickel200/Nickel201 Purity Over 99.6% Pure Nickel Strip for Electric Bicycle

General Description

Commercially wrought Nickel 200 ( UNS N02200) , a grade of pure nickel contains 99.2% nickel, has excellent mechanical properties, magnetic properties, high thermal, electrical conductivity and excellent resistance to many corrosive environment. Nickel 200 is useful in any environment below 600℉(315℃). It has highly resistance to neutral and alkaline salt solutions. Nickel 200 also has low corrosion rates in neutral and distilled water.

The applications of pure nickel includes food processing equipment, magnetostrictive devices and rechargeable batteries, computers, cellular Phone, power tools, camcorders and so on.

Chemical Composition

Alloy Ni% Mn% Fe% Si% Cu% C% S%
Nickel 200 Min 99.2 Max 0.35 Max 0.4 Max 0.35 Max 0.25 Max 0.15 Max 0.01

Physical Data

Density 8.89g/cm3
Specific Heat 0.109(456 J/kg.℃)
Electrical Resistivity 0.096×10-6ohm.m
Melting Point 1435-1446℃
Thermal Conductivity 70.2 W/m-K
Mean Coeff Thermal Expansion 13.3×10-6m/m.℃

Typical Mechanical Properties

Mechanical Properties Nickel 200
Tensile Strength 462 Mpa
Yield Strength 148 Mpa
Elongation 47%

Our Production Standard

Bar Forging Pipe Sheet/Strip Wire
ASTM ASTM B160 ASTM B564 ASTM B161/B163/B725/B751 AMS B162 ASTM B166

Main Composition %
Ni Mn Si
NiMn2 Bal. 1.5-2.5 0.3
NiMn3 Bal. 2.3-3.3 0.3
NiMn5 Bal. 4.6-5.4 0.5

Code No. Dia. mm TS. N/mm2 Elongation %
NiMn2 ≤6.0 ≥350 ≥20
NiMn3 ≤6.0 ≥350 ≥20
NiMn5 ≤6.0 ≥350 ≥20

Ni200/Ni201/Nickel200/ Nickel 201 Purity Over 99.6% Pure Nickel Strip For Electric Bicycle
