Batteries 0.005mm Thickness Pure Nickel Foil Width 0.2mm Not Powder
Batteries 0.005mm Thickness Pure Nickel Foil Width 0.2mm Not Powder
Batteries 0.005mm Thickness Pure Nickel Foil Width 0.2mm Not Powder
Batteries 0.005mm Thickness Pure Nickel Foil Width 0.2mm Not Powder
Batteries 0.005mm Thickness Pure Nickel Foil Width 0.2mm Not Powder
Batteries 0.005mm Thickness Pure Nickel Foil Width 0.2mm Not Powder
Specifications
Brand Name :
TANKII
Model Number :
N200 N201
Certification :
ISO,ROHS
Place of Origin :
China
MOQ :
20KG
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100,000/Month
Packaging Details :
in roll, wooden case outside
Type :
Nickel Strip
Grade :
Pure nickel 99.6%
Powder Or Not: :
Not Powder
Application :
Batteries, industries of electric tool and special lights
Width :
Up to 350mm wide
Thickness :
0.002 to 2.50 mm
Description

Purity ＞ 99.6 % 0.005mm Thickness Pure Nickel Foil , Width 0.2mm Nickel Coil

Product Description

Nickel 201 (UNS N02201/W.Nr. 2.4061 and 2.4068) is the low-carbon version of Nickel 200. Typical applications are caustic evaporators, combustion boats, plater bars, and electronic components. Nickel 201, because of its low base hardness and lower work-hardening rate, is particularly suited for spinning and cold forming. It is preferred to Nickel 200 for applications involving exposure to temperatures above 600°F (315°C).

.

Nickel Strip Capabilities

Grade

Pure Nickel Strip 99.6% / 99.9%

Thickness

0.02 to 2.50 mm

Tolerances

+/- 5% (special tolerances is available)

Width

Up to 350mm wide

Coil size

Up to 80 kg without welds

Temper Ranges

Annealed to Full Hard

Nickel Strip Chemical requirements

Grade

Ni+Co

Cu

Si

Mn

C

Mg

S

P

Fe

N4

99.9

0.015

0.03

0.002

0.01

0.01

0.001

0.001

0.04

N6

99.6

0.10

0.10

0.05

0.10

0.10

0.005

0.002

0.10

Ni201

99.0

≤0.25

≤0.35

≤0.35

≤0.02

/

≤0.01

/

≤0.40

Ni200

99.0

0.20

0.30

0.30

0.15

/

0.01

/

0.40

Nickel Strip Product Precision

Thickness

Thickness allowance

Burr height

Width scope and tolerance

2≤w<10

10≤w<50

50≤w<100

100≤w<150

150≤w<200

200≤w

0.02≤t<0.05

±0.003

≤0.005

±
0.05

±0.10

±0.15

±0.20

±0.30

±0.50

0.05≤t<0.1

±0.005

≤0.01

0.1≤t<0.2

±0.008

≤0.015

0.2≤t<0.3

±0.012

≤0.02

0.3≤t<0.4

±0.015

≤0.03

±
0.10

±0.15

±0.25

±0.50

±0.80

±1.00

0.4≤t<0.6

±0.025

≤0.05

0.6≤t<0.8

±0.030

≤0.06

±
0.30

±0.40

±0.50

±0.50

±0.80

±1.00

0.8≤t<1.0

±0.040

1.0≤t<1.2

±0.050

≤0.08

±
0.50

±0.50

±0.80

±1.00

±1.00

±1.50

1.2≤t<1.4

±0.060

1.4≤t<1.7

±0.070

≤0.10

1.7≤t<2.0

±0.080

Batteries 0.005mm Thickness Pure Nickel Foil Width 0.2mm Not Powder

Properties of Pure Nickel Strip:

  1. Higher electrical conductance
  2. Raised Curie Temperature
  3. Superior Magnetostrictive Properties
  4. Excellent thermal conductivity

Applications of Nickel 200 Strip:

  1. Manufacturing artificial synthetic fibers.
  2. Chemical Treatment and Preservation.
  3. Aerospace Industry.
  4. Cathode tap
  5. Cell connector

Batteries 0.005mm Thickness Pure Nickel Foil Width 0.2mm Not Powder
