Bright Surface Nichrome Ribbon Resistance Alloy For Medical Machinery
Bright Surface Nichrome Ribbon Resistance Alloy For Medical Machinery
Bright Surface Nichrome Ribbon Resistance Alloy For Medical Machinery
Bright Surface Nichrome Ribbon Resistance Alloy For Medical Machinery
Bright Surface Nichrome Ribbon Resistance Alloy For Medical Machinery
Bright Surface Nichrome Ribbon Resistance Alloy For Medical Machinery
Bright Surface Nichrome Ribbon Resistance Alloy For Medical Machinery
Bright Surface Nichrome Ribbon Resistance Alloy For Medical Machinery
Specifications
Brand Name :
Tankii
Model Number :
Nichrome 80/20
Certification :
ISO 9001
Place of Origin :
China
MOQ :
30 KG
Price :
22USD/KG
Payment Terms :
T/T, Western Union
Supply Ability :
20000KG/MONTH
Delivery Time :
5-30DAYS
Packaging Details :
WOODEN CASE ,CARTON
Product name :
Nichrome 80/20 Strip nickel chromium Ribbon Resistance Alloy For Medical machinery
Shape :
Strip
Surface :
Bright
Color :
Gray
Material :
Nichrome
Size :
Customized
Delivery :
Depends on the quantity
Description

Nichrome 80/20 Strip nickel chromium Ribbon Resistance Alloy For Medical machinery

Nickel Chromium Alloy Introduction:
Nickel Chromium alloy has high resistivity, good anti-oxidation properties, high temperature strength, very good form stability and weld ability. It is widely used in electrical heating element material, resistor, industrial furnaces, etc.

Detailed Description:
Grade: NiCr 80/20 is also called Chromel A, Nikrothal 80, N8, Nichrome V, HAI-NiCr 80, Tophet A, Resistohm 80, Cronix 80, Protoloy, Nikrothal 8, Alloy A, MWS-650, Stablohm 650, NCHW1

We also produce other kind of nichrome resistance wire, such as NiCr 70/30,NiCr 60/15,NiCr 60/23,NiCr 35/20, Karma,Evanohm

Chemical Composition and Propertes:

Nickel chromium
Grade Ni80Cr20 Ni70Cr30 Ni60Cr23 Ni60Cr15 Ni35Cr20 Karma Evanohm

Nominal composition

%

 Ni Bal Bal 58.0-63.0 55.0-61.0 34.0-37.0 Bal Bal
Cr 20.0-23.0 28.0-31.0 21.0-25.0 15.0-18.0 18.0-21.0 19.0-21.5 19.0-21.5
Fe ≤1.0 ≤1.0 Bal Bal Bal 2.0-3.0 --

Al 1.0-1.7

Ti 0.3-0.5

Al 2.7-3.2

Mn0.5-1.5

Al 2.7-3.2

Cu2.0-3.0
Max continuous Operating Temperature(°C) 1200 1250 1150 1150 1100 300 1400

Resisivity

(Ω/cmf,20°C)

 1.09 1.18 1.21 1.11 1.04 1.33 1.33

Resisivity

(μΩ/m,60°F)

 655 704 727 668 626 800 800

Density

(g/cm³)

 8.4 8.1 8.4 8.2 7.9 8.1 8.1

Tensile Strength

(N/mm²)

 750 875 800 750 750 780 780


Product: Nichrome Strip/Nichrome Tape/Nichrome Sheet/Nichrome Plate

Grade: Ni80Cr20/Resistohm 80/Chromel A

Chemical Composition: Nickel 80%, Chrome 20%

Resistivity: 1.09 ohm mm2/m

Condition: Bright, Annealed, Soft

Surface: BA, 2B, polished

Dimension: Width 1~470mm, Thickness 0.005mm~7mm

We also produce NiCr 60/15, NiCr 70/30, NiCr 60/23, NiFe80, NiFe50, NiFe42,NiFe36, etc.

Producer: Shanghai Tankii Alloy Material Co., Ltd.

Shanghai Tankii Alloy Material Co., Ltd. is a professional producer of nichrome strip, nichrome sheet, nichrome foil.
Bright Surface Nichrome Ribbon Resistance Alloy For Medical MachineryBright Surface Nichrome Ribbon Resistance Alloy For Medical Machinery
