Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Resistance
Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Resistance
Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Resistance
Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Resistance
Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Resistance
Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Resistance
Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Resistance
Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Resistance
Specifications
Brand Name :
TANKII
Model Number :
CuNi44
Certification :
ISO9001:2008
Place of Origin :
Shanghai,China
MOQ :
20kg
Price :
To negotiate
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000+TON+YEAR
Delivery Time :
7-12 DAYS
Packaging Details :
Spool, Coil, Carton, Wooden case as to per client's demands
Color :
Gold / Silver
Material :
Copper Nickel
Usage :
Electric Tube/ aero-engine material / High temperature Processing
Package :
According to client's demands
Feature :
Soft, Annealed, Good Malleability
Resistivity :
Low Resistivity
Description

Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Reaiatance

Description

Material: CuNi1, CuNi2, CuNi6, CuNi8, CuNi10, CuNi14, CuNi19, CuNi23, CuNi30, CuNi34, CuNi44 in form of strip/heet/plate/falt wire/ribbon
As a big manufacturer and exporter in China on the line of electric resistance alloy, we can supply all kinds of electric resistance alloy wire and strips (resistance steel wire and strips),

Advantage
Due to has high tensile strength and increased resistivity values, TANKII copper nickel alloy wires are the first choice for applications as resistance wires. With the different nickel amount in this product range, the characteristics of the wire can be chosen according to your requirements. Copper nickel alloy wires are available as bare wire, or enamelled wire with any insulation and self-bonding enamel. Furthermore, litz wire made of enamelled copper nickel alloy wire are available.

Application

Copper-nickel alloy contains specific minor amounts of additional elements to achieve precise values for the temperature coefficient of resistivity. Careful control of melting and conversion practices results in a very low level of pinholes at ultra-thin thicknesses. The alloy is used extensively for foil resistors and strain gauges.

Low-voltage circuit breaker, thermal overload relay, electrical heating cable, electrical heating mats, snow melting cable and mats, ceiling radiant heating mats, Floor heating mats & Cables, Freeze protection cables, electrical heat tracers, PTFE heating cables, hose heaters, and other low-voltage electrical product
Size
Wires: 0.018-10mm Ribbons: 0.05*0.2-2.0*6.0mm
Strips: 0.05*5.0-5.0*250mm Bars: D10-100mm

Properties of CuNi44


Max Continuous Service Temp
400ºC

Resisivity at 20ºC
0.49±5%ohm mm2/m

Density
8.9 g/cm3

Thermal Conductivity
-6(Max)

Melting Point
1280ºC

Tensile Strength,N/mm2 Annealed,Soft
340~535 Mpa

Tensile Strength,N/mm3 Cold Rolled
680~1070 Mpa

Elongation(anneal)
25%(Min)

Elongation(cold rolled)
≥Min)2%(Min)

EMF vs Cu, μV/ºC (0~100ºC)
-43

Micrographic Structure
austenite

Magnetic Property
Non

Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Resistance

Non magnetic Copper Nickel Alloy Strip Gold / Silver Color Good Wear Resistance
