Low Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat Wire
Low Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat Wire
Low Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat Wire
Low Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat Wire
Low Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat Wire
Low Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat Wire
Low Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat Wire
Low Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat Wire
Specifications
Brand Name :
TANKII
Model Number :
NiCr30/20
Certification :
ISO9001:2008
Place of Origin :
Shanghai, China
MOQ :
20kg
Price :
To negotiate
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000+TON+YEAR
Delivery Time :
7-12 days
Packaging Details :
Spool, coil, carton, wooden case with plastic film according to custom's requirements
Type :
Ribbon/ Flat wire
Use :
Heating Wire Hot Knife
Melting Point :
1380~1400
Finish :
Polished
Surface :
Bright, Smooth
Property :
Heat Electric Alloy
Description

Low Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat Wire

NiCr30/20 is a nickel-chromium alloy (NiCr alloy) characterized by High resistivity, good oxidation resistance,very good form stability,good ductility and excellent weldability. It is suitable for use at temperatures up to 1100°C.
Typical applications for NiCr30/20 are used in olid hot plates,open coil heaters in HVAC systems,night-storage heaters,convection heaters,heavy duty rheostats and fan heaters. And also used for heating cables and rope heaters in defrosting and de-icing elements,electric blankets and pads, car seats,baseboard heaters,floor heaters and resistors.

Our advantage:High quality,short delivery time,small MOQ.
Characteristics:Stable performance; Anti-oxidation; Corrosion resistance; High temperature stability; Excellent coil-forming ability; Uniform and beautiful surface condition without spots.

Usage:Resistance heating elements;Material in metallurgy;Household appliances;Mechanical manufacturing and other industries.

Normal composition%

C P S Mn Si Cr Ni Al Fe Other
Max
0.08 0.02 0.015 1.00 1.0~2.0 18.0~21.0 30.0~34.0 - Bal. -



Typical Mechanical properties(1.0mm)

Yield strength Tensile Strength Elongation
Mpa Mpa %
340 675 35


Typical Physical properties

Density (g/cm3) 7.9
Electrical resistivity at 20ºC(Om*mm2/m) 1.04
Conductivity coefficient at 20ºC (WmK) 13
Coefficient of thermal expansion
Temperature Coefficient of Thermal Expansion x10-6/ºC
20 ºC- 1000ºC 19

Specific heat capacity
Temperature 20ºC
J/gK 0.50
Melting point (ºC) 1390
Max continuous operating temperature in air (ºC) 1100
Magnetic properties non-magnetic

Low Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat WireLow Magnetic Silver Grey Nichrome High Resistance Ribbon, ni30cr20 Flat Wire
