Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire
Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire
Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire
Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire
Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire
Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire
Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire
Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire
Specifications
Brand Name :
TANKII
Model Number :
Ni60Cr15
Certification :
ISO9001:2008
Place of Origin :
Shanghai, Tankii
MOQ :
20kg
Price :
TO negotiate
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000+TON+YERA
Delivery Time :
7-12 DAYS
Packaging Details :
Spool, Coil, Carton, Wooden Case with Plastic Film According to Custom's Requirements
Colour :
Silver White, Metallic or Polished
Type :
Bare Round Wire/ Flat Wire
Application :
Furnace, Household Appliance, Storage Heaters
Conductor Type :
Solid
Model :
NCHW-2
Condition :
Soft, Half Hard, Hard
Description

Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire

Nickel Chromium Alloy Introduction:
Nickel Chromium alloy has high resistivity, good anti-oxidation properties, high temperature strength, very good form stability and weld ability. It is widely used in electrical heating element material, resistor, industrial furnaces, etc.

A Resistance Alloy used in electrical heating application. It is recommended for use in dry air applications up to 2150 degrees F with good hot strength. It is an alloy of nickel and chromium with high electrical resistance; used for resistance heating elements. Nichrome 80/20 is an ideal material, because it has relatively high resistance and forms an adherent layer of chromium oxide when it is heated for the first time. Material beneath the wire will not oxidize, preventing the wire from breaking or burning out.

Applications:These elements are commonly found in precision heating applications such as Medical Diagnostics, Satellite, and Aerospace; Electrical appliance industry; Ironing machines, water heaters, plastic moulding dies, soldering irons, metal sheathed tubular elements, cartridge elements

Main Advantage and Application

1. Nickel-chromium, nickel-chromium alloy with high and stable resistance, corrosion resistance, surface oxidation resistance is good, a better under high temperature and seismic strength, good ductility, good workability and weldability.

2.Our Products widely apply to chemical industry, metallurgy mechanism, glass industry, ceramic industry, home appliance area and so on.

Service

1.fine after-sale services
2.small order accepted
3.samples available

Main Properties

Alloy Nomenclature Performance Cr20Ni80 Cr30Ni70 Cr15Ni60 Cr20Ni35 Cr20Ni30
Main Chemical composition Ni Rest Rest 55.0-61.0 34.0-37.0 30.0-34.0
Cr 20.0-23.0 28.0-31.0 15.0-18.0 18.0-21.0 18.0-21.0
Fe ≤1.0 ≤1.0 Rest Rest Rest
Max. continuous service temp. of element(ºC) 1200 1250 1150 1100 1100
Resistivity at 20ºC (μΩ·m) 1.09 1.18 1.12 1.0 1.04
Density(g/cm3) 8.40 8.10 8.20 7.90 7.90
Thermal conductivity (KJ/m·h·ºC) 60.3 45.2 45.2 43.8 43.8
Coefficient of lines expansion(α×10-6/ºC) 18.0 17.0 17.0 19.0 19.0
Melting point approx.( ºC) 1400 1380 1390 1390 1390
Elongation at rupture(%) >20 >20 >20 >20 >20
Micrographic structure austenite austenite austenite austenite austenite
Magnetic properties nonmagnetic nonmagnetic Weak magnetic Weak magnetic Weak magnetic


Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon WireNicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire

Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire

Nicr60 /15 Flat Nicr Alloy Nchw-2 Storage Heater Nichrome Ribbon Wire
