Specifications
Steel Number :
1.03545
Type :
Steel Tee
Standard :
ASME B16.25
Material :
p235gh
Description
P235GH SCHEDULE 40 STANDARD STEEL PIPE FITTINGS SCH80 1.0345 ELBOW TEE CS REDUCING TEE
P235GH SCHEDULE 40 STANDARD STEEL PIPE FITTINGS SCH80 1.0345 ELBOW TEE CS REDUCING TEE
Material Specifications
Grade: P235GH
Number: 1.0345
Classification: Non-alloy quality steel
Density: 7.85 g/cm³
Applicable Standards
  • EN 10028-2: 2009 Flat products made of steels for pressure purposes. Non-alloy and alloy steels with specified elevated temperature properties
  • EN 10216-2: 2014 Seamless steel tubes for pressure purposes. Technical delivery conditions. Non-alloy and alloy steel tubes with specified elevated temperature properties
  • EN 10217-5: 2002 Welded steel tubes for pressure purposes. Submerged arc welded non-alloy and alloy steel tubes with specified elevated temperature properties
  • EN 10217-2: 2002 Welded steel tubes for pressure purposes. Electric welded non-alloy and alloy steel tubes with specified elevated temperature properties
  • EN 10253-2: 2007 Butt-welding pipe fittings. Non alloy and ferritic alloy steels with specific inspection requirements
  • EN 10273: 2007 Hot rolled weldable steel bars for pressure purposes with specified elevated temperature properties
P235GH Schedule 40 ASME B16.25 Steel Tee and Reducing Tee Pipe Fittings
Chemical Composition (%) - EN 10028-2-2003
Element Composition
C max 0.16
Si max 0.35
Mn 0.6 - 1.2
Ni max 0.3
P max 0.025
S max 0.015
Cr max 0.3
Mo max 0.08
V max 0.02
N max 0.012
Nb max 0.02
Ti max 0.03
Al max 0.02
Cu max 0.3
Cr+Cu+Mo+Ni < 0.7
Mechanical Properties
Tensile Strength (Rm)
Nominal Thickness (mm) Tensile Strength (MPa) (+N)
to 100 360-480
100 - 150 350-480
150 - 250 340-480
Minimum Yield Strength (ReH)
Nominal Thickness (mm) Minimum Yield Strength (MPa) (+N)
to 16 235
16 - 40 225
40 - 60 215
60 - 100 200
100 - 150 185
150 - 250 170
Impact Energy (KV)
Direction Temperature Impact Energy (J)
Transverse (+N) -20°C 27
0°C 27
+20°C 40
Longitudinal -10°C 28
0°C 40
+20°C 47
Min. Elongation at Fracture (A): 24-25% (+N)
Equivalent Grades
Region Standard Grade
EU EN P235GH
USA A285 / A285Gr.C
Germany DIN,WNr 1.0345 / ASt35 HI / StE255
Japan JIS SB410 / SGV410 / SPV235 / SPV24
France AFNOR A37AP / A37CP
England BS 141-360 / 161Gr.360
Italy UNI Fe360-1KG / Fe360-1KW / FeE235
Belgium NBN D37-1.2 / E37-1.2
Spain UNE A37RCI
China GB 20
Sweden SS 1330 / 1330-01
Poland PN St36K
Czechia CSN 11364 / 11366
Finland SFS Fe37BP
Austria ONORM St35KW
Russia GOST 12k
Inter ISO P3
India IS Grade1
