Specifications
Standard :
EN1092-1 Type 01
Steel Number :
1.0503
Type :
EN1092 Flanges
Material :
C45
Description
EN1092 C45 Forged Steel Flange 1.0503
Product Overview

EN1092 C45 forged steel flange manufactured from 1.0503 steel material, compliant with B16.9 standards for forged steel flanges.

Material Specifications
Grade C45
Number 1.0503
Classification Non-alloy quality steel
Applicable Standards
  • EN 10277-2: 2008 - Bright steel products for general engineering purposes
  • EN 10083-2: 2006 - Steels for quenching and tempering
  • EN 10250-2: 2000 - Open steel die forgings for general engineering purposes
Chemical Composition (%) - EN 10277-2-2008

Cr + Mo + Ni = max 0.63

Element Content Range
C (Carbon) 0.43 - 0.5
Si (Silicon) max 0.4
Mn (Manganese) 0.5 - 0.8
Ni (Nickel) max 0.4
P (Phosphorus) max 0.045
S (Sulfur) max 0.045
Cr (Chromium) max 0.4
Mo (Molybdenum) max 0.1
Mechanical Properties
Tensile Strength (Rm)
Nominal Thickness (mm) Tensile Strength (+N) MPa
to 16 620
16 - 100 580
100 - 250 560
250 - 500 540
500 - 1000 530
Nominal Thickness (mm) Tensile Strength (+C) MPa
5 - 10 750-1050
10 - 16 710-1030
16 - 40 650-1000
40 - 63 630-900
63 - 100 580-850
Yield Strength
Nominal Thickness (mm) Upper Yield Strength (+N) MPa
to 100 305
100 - 250 275
250 - 500 240
500 - 1000 230
Nominal Thickness (mm) 0.2% Proof Strength (+C) MPa
5 - 10 565
10 - 16 500
16 - 40 410
40 - 63 360
63 - 100 310
Elongation
Nominal Thickness (mm) Min. Elongation at Fracture (+C) %
5 - 10 5
10 - 16 6
16 - 40 7
40 - 63 8
63 - 100 8
Nominal Thickness (mm) Min. Elongation Lo = 5,65 √ So (+N) %
to 16 14
16 - 100 16
100 - 250 16
Hardness
Condition Brinell Hardness (HBW)
+S 255
+A 207
+SH 172 - 242
Material Properties
  • Weldability: Can be welded with precautions due to medium-high carbon content
  • Hardenability: Low hardenability in water or oil; suitable for surface hardening with high hardness of hardened shell
International Equivalent Grades
Region Standard Equivalent Grade
EU EN C45 C45
USA ASTM 1042, 1045, Gr.1043
Germany DIN, WNr C45
Japan JIS S45C
France AFNOR AF65C45, C45
England BS 070M46, 50HS
Italy UNI 1C45, C45
Spain UNE C45k
China GB 45
Sweden SS 1650
Poland PN 45
Czechia CSN 12050
Austria ONORM C45SW
Russia GOST 45
International ISO C45
