Specifications
Pressure :
300LBS
Place of Origin :
China
Model Number :
1/2''-48''
Type :
Forged Steel Flanges
Material :
304L
Name :
Lap joint Flange
Brand Name :
Best
Certification :
API/CE/ISO/PED
MOQ :
1 Pcs
Price :
1 usd/pcs
Payment Terms :
L/C/ TT
Supply Ability :
100000 Ton/Year
Delivery Time :
5-8 working days
Packaging Details :
Standard export seaworthy package,by wooden box,or as required
Description
304L Forged Steel Flanges
Product Overview
Threaded flanges DIN 2565-2567, DIN 2558 blind flanges DIN 2527, PN 6 - PN 100 block flanges DIN 28117, PN 10 - PN 40.
Product Specifications:
Name: Lap Joint Flange
Pressure: 300 lbs
Material: 304L
Manufacturing: Forged Steel Flanges
What is a Flange?
A flange is defined as a plate type device, normally round, that is attached to the end of a pipe, fitting, valve or other object to facilitate the assembly and disassembly of a piping system.
Flanges are manufactured in all the different materials to match the material of the pipe and fittings to which they are being attached. While some flanges are made of cast iron, the vast majority of flanges are forged carbon steel.
Pressure Ratings
Forged steel flanges are made in seven primary ratings: Class 150, Class 300, Class 400, Class 600, Class 900, Class 1500 & Class 2500.
Flange Types
  • Weld Neck Flanges
  • Slip-On Flanges
  • Lap Joint Flanges
  • Threaded Flanges
  • Socket Weld Flanges
  • Blind Flanges
Forged Flanges Specifications
Size: ½" TO 54"
Pressure Rating: 150#, 300#, 600#, 900#, 1500#, 2500#
Standards: ASME B 16.5, ASME B 16.47, API 6A
Type: SORF, WNRF, SWRF, BLRF, Threaded, etc.
Specials: Spacers, Spectacle Blinds, Drip Rings, RTJ, Tongue, Groove, Orifice, etc.
Available Materials
Carbon Steel: A-105, A-350 LF2 [NACE + HIC], etc.
Alloy Steel: F-5, F-9, F-11, F-22, F-91, etc.
Stainless Steel: SS 304, SS 304L, SS316, SS 316L, SS 316Ti, SS 321, SS 347, SS 304H, 317L, 347H, etc.
Duplex SS: F-51, F-55
High Strength Steel: A694 Gr 52, 60, 65, 70, AISI 4130, 4140
Nickel Alloys: Monel 400, Inconel 625, Inconel 825, Alloy 20, etc.
150lb Flange Dimensions
Nominal Bore Pipe OD A Flange dia. B Raised Face dia. D Flange Thickness T Welding Neck Slip-on Screwed Socket-weld Bolt PCD No. of Bolts Bolt Hole dia.
1521.488.934.911.147.615.960.3415.9
2027.098.442.912.752.415.969.8415.9
2534.1107.950.814.355.617.579.4415.9
3242.9117.563.515.957.120.688.9415.9
4048.4127.073.017.561.922.298.4415.9
5060.3152.492.119.063.525.4120.6419.0
6573.0177.8104.822.269.828.6139.7419.0
8088.9190.5127.023.869.830.2152.4419.0
90101.6215.9139.723.871.431.7177.8819.0
100114.3228.6157.223.876.233.3190.5819.0
125141.3254.0185.723.888.936.5215.9822.2
150165.1279.4215.925.488.939.7241.3822.2
150168.3279.4215.925.488.939.7241.3822.2
200219.1342.9269.928.6101.644.4298.4822.2
250273.1406.4323.830.2101.649.2361.91225.4
300323.9482.6381.031.7114.355.6431.81225.4
350355.6533.4412.734.9127.057.1476.21228.6
400406.4596.9469.936.5127.063.5539.71628.6
450457.2635.0533.439.7139.768.3577.81631.7
