3000LB 4inch Sockets Butt Weld Reducing Tee / 40mm solvent weld tee
3000LB 4inch Sockets Butt Weld Reducing Tee / 40mm solvent weld tee
3000LB 4inch Sockets Butt Weld Reducing Tee / 40mm solvent weld tee
3000LB 4inch Sockets Butt Weld Reducing Tee / 40mm solvent weld tee
3000LB 4inch Sockets Butt Weld Reducing Tee / 40mm solvent weld tee
3000LB 4inch Sockets Butt Weld Reducing Tee / 40mm solvent weld tee
3000LB 4inch Sockets Butt Weld Reducing Tee / 40mm solvent weld tee
3000LB 4inch Sockets Butt Weld Reducing Tee / 40mm solvent weld tee
Specifications
Brand Name :
PLS
Model Number :
DN15-DN5000
Certification :
CE,API,PED,ABS,CCS,ISO9001
Place of Origin :
Cangzhou ,Hebei Pro,China
MOQ :
1PC
Price :
Negotiate
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Piece/ per Month
Packaging Details :
Plastic Bag,Carton box, Wooden case or according to your requirement.
MOQ :
1pc
Rating Pressure :
2000/3000/9000 LBS
Rating Pressure WT :
SCH40/SCH80/SCH160/XXS
Thread :
BSPP BSPT NPT
Connection :
Male and Female
Standard :
ANSI,EN,GOST
Surface :
Galvanized,Normal black,Oil-rust
OEM service: :
Available
Usage: :
Joining Pipe Lines
Head Code :
Round
Description

Products Decription:Industry high pressure sockolet weld tee galvanized ASME B16.11 3000LB 4"Forged Steel Fittings

Industy forged steel fittings.high pressure socklolet weld tee; galvanized tee ,ASME B16.11 forged steel fittings, 3000lb forged steel fittings

Customizable forged steel sockolet weld fittings tee galvanized ASME B16.11
Material Stainless steel, carbon steel, copper, iron, etc
Standard BS,DIN,ANSI
Design OEM
Size 1/8" to 6"
Surface Galvanized,Normal black,Oil-rust
Weight Super heavy,heavy,medium,light
Model Elbows, Tees, Crosses, Bends, Unions, Bushings, Lateral Y Branches, Sockets, Nipples, Hexagon/Round Caps, Plugs, Lock nuts, Flanges, Side Outlet Tees, Side Outlet Elbows, etc.
Connection Male, Female, pipe fittings
Shape Equal, Reducing
Mechanical Properties Tensile Strength >= 330 MPa
Elongation >= 8%
Hardness < 163
Hydraulic Test Working Pressure: Max 1.5 MPa
Test Pressure: Max 2.5 MPa
Temperature -20-120 °C

Class 3000

NPS Socket Bore Depth Socket Bore dia
B J D
1/2 21.95
21.70		 10 16.6
15
3/4 27.30
27.05		 13 21.7
20.2
1 34.05
33.80		 13 27.4
25.9
1¼ 42.80
42.55		 13 35.8
34.3
1½ 48.90
48.65		 13 41.7
40.1
2 61.35
61.10		 16 53.5
51.7
2½ 74.20
73.80		 16 64.2
61.2
3 90.15
89.80		 16 79.5
46.4
4 115.80
115.45		 19 103.8
100.7
NPS Socket
WT		 Body
WT		 Center to bottom of socket
C G A
1/2 4.65
4.10		 3.75 15.5
3/4 4.90
4.25		 3.90 19.5
1 5.70
5.00		 4.55 22
1¼ 6.05
5.30		 4.85 27
1½ 6.35
5.55		 5.10 32
2 6.95
6.05		 5.55 38
2½ 8.75
7.65		 7.00 41.5
3 9.50
8.30		 7.60 57.5
4 10.70
9.35		 8.55 66.5
3000LB 4inch Sockets Butt Weld Reducing Tee / 40mm solvent weld tee

General notes:

  • Dimensions are in millimeters unless otherwise indicated.
  • Socket Bore (B) - Maximum and minimum dimensions.
  • Bore Diameter (D) - Maximum and minimum dimensions.
  • Socket wall thickness - (C) - Average of Socket wall thickness.
  • Dimensional tolerances center to bottom of socket - (A)
    NPS 1/2 and NPS 3/4 = +/- 1.5 mm
    NPS 1 to NPS 2 = +/- 2 mm
    NPS 2½ to NPS 4 = +/- 2.5 mm
