LDX2101 duplex stainless steel plate UNS S32101
LDX2101 duplex stainless steel plate UNS S32101
Specifications
Place of Origin :
Suzhou, China
Brand Name :
AIWEN
Certification :
SGS, BV, TUV
Model Number :
UNS S32101(2101)
Grade :
300 Series
Type :
Coil
Standard :
AISI|GB|DIN
Length :
Per customer requirement
Thickness :
0.2-50mm
Width :
1500, 2000mm
Application :
Shipbuilding
Product form :
Plate, strip, sheet...
Service available :
Splitting, cutting, packing, shipping
MOQ :
10 Metric Tons
Price :
Available per request
Packaging Details :
Wooden pallet
Delivery Time :
45 days
Payment Terms :
T/T
Supply Ability :
500MT/month
Loading port :
Shanghai Port, China
Description

LDX2101 duplex stainless steel plate UNS S32101

General introduction

UNS S32101 is a duplex (austenitic-ferritic) stainless steel with relatively low contents of alloying elements. The grade has high mechanical strength, similar to that of other duplex grades. Its good corrosion resistance is on par with that of most standard stainless steel grades. Combined, these properties can be utilised to optimise design with respect to strength, maintenance, durability and long-term cost efficiency.

Main characteristics:

  • High strength - approximately twice as high proof strength as austenitic stainless steels ASTM 304 and 316
  • Very good resistance to stress corrosion cracking
  • Good resistance to general corrosion and pitting
  • High energy absorption
  • Physical properties that offer design advantages
  • Ease of fabrication and good toughness
  • Very good weldability

Applications

General-purpose applications and environments:

  • Building and construction
  • Storage tanks
  • Reinforcement bars
  • Water piping

Microstructure

The balanced chemical composition of UNS S32101 results in a microstructure containing approximately equal amounts of ferrite and austenite after annealing at a temperature of 1050°C (1920oF). Due to its relatively low alloying content, UNS S32101 is less prone to precipitaition of intermetallic phases than other duplex steels.

The high nitrogen content results in rapid re-formation of austenite in weld thermal cycles.

Standards

  • UNS S32101

Chemical composition (nominal) %

C Si Mn P S Cr Ni N Mo
0.030 1.0 5.0 0.04 0.03 21.5 1.5 0.22 0.3

Mechanical properties

Mechanical properties

UNS S32101 has high mechanical strength due to its duplex microstructure and high nitrogen content.

In Table 1 the minimum and typical values for the grade are presented. The mechanical properties at elevated temperatures are shown in Table 2.

Minimum values Typical values
P H C P (15mm) H (4mm) C (1mm)
Proof strength Rp0.2 MPa 450 480 530 480 570 600
Tensile strength Rm MPa 650 680 700 700 790 840
Elongation Ab % 30 30 - 38 38 40
Impact toughness KV1) J 60 60 - 100 - -
Hardness HB 230 230 230
