Specifications
Place of Origin :
Guangdong, China
Brand Name :
CNLINKO
Model Number :
YT-RJ45-CPE-01-001
MOQ :
2
Price :
US$5.21-10.42
Type :
RJ45
Application :
Signal
Gender :
male and female
Connector type :
ethernet rj45 connector
Withstanding Voltage :
1000V dc
Durability :
500 circles
Material :
PBT, BLACK
Contact :
Copper Alloy
Coupling ring :
/
Working Temperature :
-40℃ ~ 80℃
Connecting mode :
1/4 bayonet locking
waterproof rate :
ip67
Rated current :
1.5A
Description

IP65 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable Connector

Product Description

Compliant with D registration or CAT3e according to EIA568B ISO/IEC11801 standards, compatible with CAT5e.
Multi-style connection design, 1/4 quick bayonet connection (YT01), quick plug (YT10).
The cable jacket has a rugged die-cast housing and a unique double clip cable sleeve.
The cable connector jacket can be used with the most common RJ45 plugs.
Waterproof and non-waterproof design, the product meets IP65/IP67 protection level when connected.
Shielding system - high frequency noise immunity and electromagnetic interference protection.

IP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable ConnectorIP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable ConnectorIP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable ConnectorIP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable ConnectorIP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable ConnectorIP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable ConnectorIP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable ConnectorIP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable ConnectorIP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable ConnectorIP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable Connector

More Hot Products

IP68 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable Connector

Specifications

IP65 Waterproof Ethernet Connector RJ45 Female to Male Cat5 Network Cable RJ45 Cable Connector

Specifications
Connecting mode Latching Lock connect
Protection level IP67
Cable specification 0.15mm2 ~ 0.2mm2 /26~24AWG
Diameter range Φ5.5mm ~Φ7mm
Contact diameter×Qty 8 Pin
Current rating(A) 5A
Operating voltage(AC.V.rms) 500V
Withstand voltage(AC.V)1min /
Contact resistance <30mΩ
Insulation resistance >500MΩ
Durability ≥750 mating&unmating cycles
Temperature rating -40°C~80°C
Method of connecting cable Solder
Prevent the combustion level UL94-V0
Material
Shell&insulated parts High performance engineering plastics
Hardware metal Zinc alloy(pearl hard chromium)
Contact pin Copper alloy(gold-plated)
Spring Stainless steel
Sealing Silica gel
Main characteristics
Sealed against dust and fluid (IP65/IP67)
Vibration resistance,impact resistance,stretching resistance
1/4 bayonet connect; socket with cover
Application industries
Stage equipment - The smart grid
Medical equipment - Server
Solar energy equipment - Ship equipment
Electric power equipment - Vehicle equipment
Communications equipment - Heavy machinery
Certifications
