Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Cnlinko
Model Number :
LP-12-C07PE-03-001
Certification :
UL,CE,ROHS,CCC,ISO9001
MOQ :
2
Price :
$6.07-7.08
Shape :
ROUND
IP level :
ip68
Type :
Signal
Application :
Industrial
Gender :
male and female, Female +male
Protection level :
IP65/IP67
Pin :
7pin
Current rating(A) :
3A
Shell & Insulated Parts :
High Performance Engineer Plastic
Hardware Matel :
Zinc Alloy (pearl hard chromium)
Connecting mode :
plug/unplug
Operating voltage :
500V
Cable Spec :
24-22AWG
Description

Cnlinko M12 7 Pin plug socket IP68 Waterproof Electrical Connector with Dust Cover

Product Description

Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust CoverCnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover

Specifications
Specifications
Connecting mode Latching Lock connect
Protection level IP65/IP67
Cable specification 0.2~03mm2 /24~22AWG
Diameter range Φ3mm ~Φ6mm
Contact diameter×Qty Φ0.8x7
Current rating(A) 3A
Temperature rise /
Withstanding voltage(AC.V)1min 1500V
Contact resistance <10mΩ
Insulation resistance >500MΩ
Durability ≥500 mating&unmating cycles
Temperature rating -40°C~80°C
Method of connecting cable Soldering
Prevent the combustion level UL94-V0
Material
Insulated parts High performance engineering plastics
Hardware metal Zinc alloy(pearl hard chromium)
Contact pin Copper alloy(gold-plated 4U)
Spring Stainless steel
Sealing Silica gel
Main characteristics
Sealed against dust and fluid (IP65/IP67)
Vibration resistance,impact resistance,stretching resistance
socket with cover
Application industries
Stage equipment - The smart grid
Medical equipment - Server
Solar energy equipment - Ship equipment
Electric power equipment - Vehicle equipment
Communications equipment - Heavy machinery
Certifications

Cnlinko M12 Metal 7 Pin Plug Socket IP68 Waterproof Electrical Connector with Dust Cover
