cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
Specifications
Brand Name :
Sun Communication
Model Number :
SMA Male Plug Right Angle Connector for RG174 lmr100 cable
Certification :
UL CE ROHS
Place of Origin :
Guangdong, China
MOQ :
100 PCS
Price :
Negotiable
Supply Ability :
10000 Unit/Units per Month
Delivery Time :
1-2weeks
Packaging Details :
Packaging Details Plastic Bag Packing
Type :
Din connector
Application :
RF
Gender :
Male
Impedance :
50 Ohm
Frequency range :
DC-3G / DC-6G
Voltage rating :
500 V(rms)
Dielectric withstan :
>1500V
Center contact res :
<1.0mΩ
Insulation resistance :
>5000MΩ
VSWR :
≤1.08 (0-2.2GHz); ≤1.1
Temperature range :
-55 ℃~+165 ℃
Durability :
≥ 500 cycles
Insertion Loss :
≤0.12dB (@2200MHz)
PIM :
≤-160dBc
Describe :
Din connector
Plating :
Gold or Nickel
Description

cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector

Feature:

> Super soft feeder telecom level

> Cable with strong flexibility , resistance to bending ,length can be customized.

> High purity oxygen free copper reinforcement signal anti-jamming and enhance the signal transmission,

increasing signal transmission distance, long service life

> Pure copper joint signals far superior alloy joints, low dissipation and more resistant to corrosion
> A new polyvinyl chloride(PVC), soft pull resistance, not easily broken

Temperature range
-65~+165°C (PE Cable -40~+85°C)
Vibration
MIL-STD-202,Method 213
Impedance 50 OHM
Frequency Range DC – 12.4GHz(0-18GHz)
Working Voltage 335V max
Withstand Voltage
 1000V rms
Center Contact
≤ 3 mΩ
Outer Contact

≤2mΩ
Insulation resistance ≥5000M OHM
Insertion loss
 ≤0.15 dB/6GHz
Durability (mating) ≥500 (cycles)
Insertion loss
 0.15dB (7.5GHz max)
VSWR

Straight Soft cable ≤1.10+0.002f

Semi-steel cable≤1.05+0.001f

Right angle Soft cable ≤1.20+0.003f

Semi-steel cable≤1.10+0.001f

Material & Plating

Body Brass Nickel plated / Alloy plated
Inner Pin Brass Gold plated
Resilient Contact Beryllium Copper Gold plated
Socket Contact Beryllium or tin bronze Gold plated
Insulator PTFE
Crimp Ferrule Copper alloy Nickel / Gold plated
O-ring sealing Silicone Rubber



cable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connectorcable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connectorcable N male to SMA male coaxial Mating Din Connector Socket Radio Frequency RF Connector
