OE-315A Screw Compressor | Giant Full-Plant Continuous Air Supply & 85dB Low Noise Design
OE-315A Screw Compressor | Giant Full-Plant Continuous Air Supply & 85dB Low Noise Design
Specifications
Brand Name :
FU PRO
Model Number :
F Series
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
20000-420000CNY
Payment Terms :
50% deposit in advance,balance 50% before shipment
Supply Ability :
Stable bulk supply, long-term orders accepted
Delivery Time :
Standard / Custom Orders: Shipment within 15-25 working days upon receipt of advance payment.
Packaging Details :
Bubble Wrap / Stretch Wrap
Model :
OE-315A Single Stage Screw Air Compressor
Rated Air Flow :
65m³/min@7.5bar(g),58.1m³/min@8.5bar(g),52.29m³/min@10bar(g),45.2m³/min@13bar(g)
Overall Size :
4600×2100×2400 mm
Working Pressure Range :
7.5 - 15.5 bar(g)
Noise Level :
63–67 d(BA)
Exhaust Interface :
G1-1/4" / G1"
Net Weight :
7760kg
Description
OE-315A Single Stage Screw Air Compressor | Huge Constant Rated Air Flow & Multi-Pressure Optional Grades

Product Introduction

OE-315A heavy-duty fixed displacement single stage screw air compressor is designed with four standard rated pressures:65m³/min@7.5bar,58.1m³/min@8.5bar,52.29m³/min@10bar,45.2m³/min@13bar. Equipped with oversized DN150 flange exhaust port for low-pressure-loss long-distance super large industrial pipeline air transmission. Overall dimension:4600×2100×2400mm, net weight 7760kg and running noise at 85dB(A). Fully load-tested before delivery, widely applied for large mining cluster, full-vehicle auto industrial park, heavy steel structure and super-large spraying production base with 24-hour continuous production, available for bulk container export.

Core Advantages

  1. Four selectable rated pressures plus massive steady fixed airflow to supply whole super industrial park non-stop production

    Full industrial pressure range from7.5~13 bar with stable constant output after setting pressure, capable of supplying hundreds of pneumatic machines simultaneously without redundant compressor installation cost.
  2. Oversize DN150 flange outlet plus optimized mute cabinet for convenient super heavy-industry main pipeline layout

    Large bore flange connection minimizes pipeline pressure drop for factory large-diameter main piping; reinforced noise reduction structure keeps 85dB quiet operation to meet international heavy industrial environmental standards.

Product Parameters





Item Specification
Model OE-315A Single Stage Screw Air Compressor
Rated Air Flow 65m³/min@7.5bar(g),58.1m³/min@8.5bar(g),52.29m³/min@10bar(g),45.2m³/min@13bar(g)
Exhaust Port DN150 Flange
Overall Size 4600×2100×2400 mm
Noise Level 85dB(BA)
Net Weight 7760kg
Application Large mining cluster, full auto manufacturing park, heavy steel fabrication & super-large industrial spraying industry

FAQ

Q1: Which factory fits OE-315A fixed-speed compressor?

A: Super-large heavy industrial parks with 24-hour non-stop full-load stable air consumption.

Q2: Can DN150 flange convert to BSPT/NPT thread?

A: Custom transition flanges available without airflow performance degradation.

Q3: Are maintenance spare parts available for full container shipment?

A: Complete filter kits and special screw lubricant can be shipped together with main machines.
