Drainage Free Removable Air Conditioner All In One Design Removable Ac Unit
Drainage Free Removable Air Conditioner All In One Design Removable Ac Unit
Drainage Free Removable Air Conditioner All In One Design Removable Ac Unit
Drainage Free Removable Air Conditioner All In One Design Removable Ac Unit
Drainage Free Removable Air Conditioner All In One Design Removable Ac Unit
Drainage Free Removable Air Conditioner All In One Design Removable Ac Unit
Specifications
Brand Name :
MS / OEM
MOQ :
10
Price :
USD 160-2700
Payment Terms :
T/T
Packaging Details :
Carton / Woden case
Model Number :
KY-20/45-79
Certification :
CB
Place of Origin :
China
Supply Ability :
Good
compressor :
Panasonic and some other well known brand
cover body :
metal sheet with powder coated
finned exchanger :
the fin is from light aluminum foil ,hydrophilic aluminum foil, epoxy resin aluminum foil, hydrophobic aluminum foil,copper foil, antique copper foil.
base tube :
internal threaded copper tube, stainless steel tube, nickel-white copper internal threaded tube.
OEM /ODM :
it is optional between OEM and ODM
markets have had :
USA,Australia,Middle East,South Korea,India,Thailand,Finland,Mongolia and etc.
laboratory :
available in the factory
Delivery Time :
7-30 days
Description

Regarding outdoor portable air conditioners, we adopt an all - in - one production model. Everything from independent design, production of condensers, evaporators and sheet metal parts, finished product assembly to testing is completed independently by ourselves.

Product Parameter

serial no. specification technical paramter technical paramter technical paramter
1 Model KY-58 KY-68 KY-79
2 Rated Cooling Capacity(W/BTU) 5800 W / 19790 BTU 6800 W / 23200 BTU 7900 W / 27000 BTU
3 Energy Efficiency Ratio (W/W) 2.58 2.72 3.0
4 Rated Voltage(V) 220 220 220
5 Rated Frequency(Hz) 50 50 50
6 Rated Cooling Power(W) 2250 2500 2625
7 Rated Cooling Current (A) 10.4 11.6 12.2
8 Maximum Input Power(W) 3480 3880 4070
9 Maximum Input Current(A) 15.8 17.6 18.5
10 Allowable Pressure of Refrigeration system(MPa) 4.2 4.2 3.0
11 Refrigerant and Charge Amount R410A:1150g R410A:1400g R410A:1400g
12 Circulating Air Volume(m³) 1200 1200 1200
13 Noíse dB(A) 57 57 57
14 Protection Category against Electric Shock I I I
15 Waterproof Grade IPx4 IPx4 IPx4
16 N.W. (kg) 90 92 98
17 Unit Size 606*558*1296 mm 606*558*1296 mm 606*558*1296 mm

Product Description
The outdoor portable air conditioner is a refrigeration device with strong flexibility and adaptability. It features an integrated design, allowing for plug - and - play operation.
It can be easily moved around and is suitable for various climates. It offers both cooling and heating functions, is energy - efficient, and is simple to operate.

Principle of the non-drainage function:

During the operation of the unit, the evaporator absorbs the heat and moisture in the air, and the moisture condenses on the fins of the evaporator, flowing downstream to the water receiving tray and then to the bottom of the condenser. The condensed water is splashed onto the fins of the condenser and evaporated by the fan blade, and then blown into the air by the condensing fan. The amount of condensation evaporation is greater than the amount of evaporation condensation, so that the water in the water receiving tray will never accumulate too much.

Due to the cooling effect of water, the condenser has a lower condensing temperature, resulting in a significant improvement in system efficiency.

If a certain required quantity is reached, the product's performance and appearance can be customized according to the local market demands of customers, so as to gain a better edge in seizing market opportunities.

Drainage Free Removable Air Conditioner All In One Design Removable Ac Unit

Drainage Free Removable Air Conditioner All In One Design Removable Ac Unit

Drainage Free Removable Air Conditioner All In One Design Removable Ac Unit
