380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter
380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter
380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter
380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter
380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter
380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter
380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter
380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter
Specifications
Brand Name :
OEM/ODM
Model Number :
Customized
Certification :
CE,ROHS ,ISO9001,ISO14001,
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1-3 sets per month
Delivery Time :
20-25days
Packaging Details :
wooden packing
Name :
380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter
Type :
Straightener & Cutter
Voltage :
380V 50Hz
Object of action :
Metal/Plastic
Power(W) :
1120
Tube Material :
Copper / Aluminum / Bundy tube
Cuuting length :
0-100m
Application :
aluminium, stainless steel and bonded tubes
Description

380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter

Specification

Item Data
Applicable copper tube Coil, TP1/2 (M/M2)
Applicable copper tube diameter Ф2.0~Ф6.5mm
Applicable copper tube wall thickness 0.2~0.5mm
Cutting length range 40mm~ unlimited
Cutting length tolerance ≤0.3mm /1000mm
Length difference among two pieces ≤0.5mm
Cutting pieces in one cycle max. 2 tubes
Cutting speed 8 cuts per minute (@L=1000mm)
One time feeding stroke continuous feeding, no limit
Coil tube pay-off device only one transmitting bridge
coils horizontal laying on ground
Total electric power 1.0kW
Pneumatic pressure 0.5~0.7MPa
Machine dimension 2600 x 1200 x 1500mm
Pay-off device dimension 2000 x 1000 x 2000mm
Total weight about 1400kg

Detailed iamge

380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter

380V 50Hz Tube Straightening Cutting Machine , Aluminum / Copper Tube Straightener Cutter

Features

1.Servo CNC, accurate locating, stable feeding.

2.High degree of automation, convenient adjustment.

3.With snapping function, little shrinking of pipe end.

Guarantee

The guarantee period is one year since the date B/L. During this period, we will offer free parts for changing if machine quality problem.

Also the spare parts can be offered in original cost after that. The freight for part sending will be paid by buyer.

Supply Ability

Supply Ability:20 Set/Sets per Month Automatic coil steel bundy aluminum copper tube pipe
