Specifications
Pattern description :
8/16 Shed
Basis Weight (g/m²) :
850
CMD Yarns Top :
0.20mm, 0.27mm 22.6 /cm PET
Air Permeability :
360 CFM @ 125 Pa
Void Volume :
811 ml/m² (55.9%)
Caliper (mm) New :
1.450
Fiber Support Index :
79
Paper Side Open Area :
/
CMD Yarns Bottom :
0.50mm 11.3 /cm PET/PA
Fiber Support Point :
170 /cm²
Drainage Index :
22.2
Caliper (mm) Critical :
0.970
Break Strength :
≥1100 N/cm
Structure :
2.5 Layer
Fabric Color :
Light Green, Light Blue
MD Yarns Top :
0.27mm 40.0 /cm PET
MD Yarns Bottom :
/
Brand Name :
ATMC
MOQ :
1pc
Price :
inquiry
Payment Terms :
L/C,D/A,D/P,T/T
Packaging Details :
Standard export ply-wood case
Elongation(50N/cm) :
≤0.40%
Description
KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for Board and Packaging Papers
The KRAFT DRAFT DLA47816SM forming fabric features an innovative coarse-mesh, 8-over-16 shed double-layer construction. By integrating an additional cross-direction (CD) yarn, it delivers superior sheet support and formation stability. This weave maximizes drainage capacity, while its coarse, large-diameter wear-side weft yarns are engineered for exceptional abrasion resistance and extended operational life.
Key Features

  • Superior Sheet Support & Drainage: Coarse 8-shed paper side structure uniquely combines high fiber support with very high drainage capacity.

  • High Top Surface Open Area: The specific weave maximizes open area on the sheet side, directly contributing to rapid and efficient dewatering.

Product Parameters
Product Name Forming Fabric KRAFT DLA47816SM
Material Polyester monofilament
Function Paper Machine
Application Light GSM Kraft Paper, Wrapping Paper, etc.
Technical 1/1.5/2/2.5/3 layers forming fabric
Width Customized
Weight Customized
Fabric Color Customized
Product Images
Double Layer Unique Combination Forming Fabric for Paper Making - KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for Board and Packaging Papers Double Layer Unique Combination Forming Fabric for Paper Making - KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for Board and Packaging Papers
Top Side View Bottom Side View
Application
Wrapping and Packing Papers, Board Grades.
Double Layer Unique Combination Forming Fabric for Paper Making - KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for Board and Packaging Papers Double Layer Unique Combination Forming Fabric for Paper Making - KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for Board and Packaging Papers
