Double Layer High-Performance Forming Fabric for Board & Packaging Paper - KRAFT DLA41816SC-450CFM Weave, Unique Fiber Support & Drainage Combination, Excellent Wear Resistance
Double Layer High-Performance Forming Fabric for Board & Packaging Paper - KRAFT DLA41816SC-450CFM Weave, Unique Fiber Support & Drainage Combination, Excellent Wear Resistance
Double Layer High-Performance Forming Fabric for Board & Packaging Paper - KRAFT DLA41816SC-450CFM Weave, Unique Fiber Support & Drainage Combination, Excellent Wear Resistance
Double Layer High-Performance Forming Fabric for Board & Packaging Paper - KRAFT DLA41816SC-450CFM Weave, Unique Fiber Support & Drainage Combination, Excellent Wear Resistance
Specifications
Pattern description :
8/16 Shed
Basis Weight (g/m²) :
850
CMD Yarns Top :
0.20mm, 0.27mm 22.6 /cm PET
Air Permeability :
360 CFM @ 125 Pa
Void Volume :
811 ml/m² (55.9%)
Caliper (mm) New :
1.450
Fiber Support Index :
79
Paper Side Open Area :
/
Brand Name :
ATMC
MOQ :
1pc
Price :
inquiry
Payment Terms :
L/C,D/A,D/P,T/T
Packaging Details :
Standard export ply-wood case
CMD Yarns Bottom :
0.50mm 11.3 /cm PET/PA
Fiber Support Point :
170 /cm²
Drainage Index :
22.2
Caliper (mm) Critical :
0.970
Break Strength :
≥1100 N/cm
Structure :
2.5 Layer
Fabric Color :
Light Green, Light Blue
MD Yarns Top :
0.27mm 40.0 /cm PET
MD Yarns Bottom :
/
Elongation(50N/cm) :
≤0.40%
Description
KRAFT DLA41816SC-450CFM Double Layer Weave, Unique Fiber Support & Drainage Combination, Excellent Wear Resistance
Optimizing the papermaking process, the KRAFT DLA41816SC features a unique coarse-mesh, double-layer architecture (8-shed over 16-shed). The integration of a supplementary CD yarn provides critical enhancement to sheet support. This configuration ensures excellent drainage capacity, while the implementation of large-diameter wear-side yarns directly contributes to remarkable fabric longevity, ideal for continuous high-output production.
Key Features

Extended Operational Lifespan: The durable wear-side yarn design directly contributes to a substantial increase in overall fabric life and service potential.

High Load & Ridge Resistance: Double MD yarn lock construction on the wear side provides exceptional resistance to high machine-direction loads and prevents CD ridging.

Product Parameters
Product Name Forming Fabric KRAFT DLA41816SC
Material Polyester monofilament
Function Paper Machine
Application Light GSM Kraft Paper, Wrapping Paper, etc.
Technical 1/1.5/2/2.5/3 layers forming fabric
Width Customized
Weight Customized
Fabric Color Customized
Product Images
Double Layer High-Performance Forming Fabric for Board & Packaging Paper - KRAFT DLA41816SC-450CFM Weave, Unique Fiber Support & Drainage Combination, Excellent Wear Resistance Double Layer High-Performance Forming Fabric for Board & Packaging Paper - KRAFT DLA41816SC-450CFM Weave, Unique Fiber Support & Drainage Combination, Excellent Wear Resistance
Top Side View Bottom Side View
Application
Wrapping and Packing Papers, Board Grades.
Double Layer High-Performance Forming Fabric for Board & Packaging Paper - KRAFT DLA41816SC-450CFM Weave, Unique Fiber Support & Drainage Combination, Excellent Wear Resistance Double Layer High-Performance Forming Fabric for Board & Packaging Paper - KRAFT DLA41816SC-450CFM Weave, Unique Fiber Support & Drainage Combination, Excellent Wear Resistance
