SSB Triple Layer Durable Paper Machine Fabric KRAFT SSB55208WM55NG-450CFM Fine Paper Side with Coarse Wear Side, High Internal Void Volume for Aggressive Dewatering
SSB Triple Layer Durable Paper Machine Fabric KRAFT SSB55208WM55NG-450CFM Fine Paper Side with Coarse Wear Side, High Internal Void Volume for Aggressive Dewatering
SSB Triple Layer Durable Paper Machine Fabric KRAFT SSB55208WM55NG-450CFM Fine Paper Side with Coarse Wear Side, High Internal Void Volume for Aggressive Dewatering
SSB Triple Layer Durable Paper Machine Fabric KRAFT SSB55208WM55NG-450CFM Fine Paper Side with Coarse Wear Side, High Internal Void Volume for Aggressive Dewatering
Specifications
Brand Name :
ATMC
Pattern description :
2/8 Shed
Basis Weight (g/m²) :
/
Price :
inquiry
CMD Yarns Top :
/
Air Permeability :
450CFM, 7100 m³ /m²h
Void Volume :
/
Payment Terms :
L/C,D/A,D/P,T/T
Caliper (mm) New :
1.330
Fiber Support Index :
111/116
Paper Side Open Area :
32.5/30.7%
CMD Yarns Bottom :
/
Fiber Support Point :
461/492 /cm²
Drainage Index :
25.7/25.6
Caliper (mm) Critical :
/
Break Strength :
≥1200 N/cm
Structure :
SSB Triple Layer
Fabric Color :
Light Blue, Light Green
MOQ :
1pc
MD Yarns Top :
/
Elongation(50N/cm) :
≤0.40%
MD Yarns Bottom :
/
Packaging Details :
Standard export ply-wood case
Description
SSB Triple Layer Durable Paper Machine Fabric KRAFT SSB55208WM55NG-450CFM Fine Paper Side with Coarse Wear Side, High Internal Void Volume for Aggressive Dewatering

KRAFT SSB55208WM55NG is a triple layer forming fabric combining a coarse plain weave paper side with an eight‑shed wear side. The paper side provides a high support point count and a high Fiber Support Index, resulting in minimal marking, clean running, and outstanding mechanical retention. The wear side features an open, coarse long‑float design with a 3:2 CD yarn ratio (paper to wear), enabling the use of medium and coarse CD yarns for excellent wear potential and dimensional stability. High internal void volume and optimized surface properties give this fabric excellent dewatering capacity. Additionally, the structure ensures high dimensional stability and good life potential for extended service.


Key Features
  • Low marking level virtually eliminates wire marks for a smooth sheet surface.
  • Clean running characteristic reduces paper machine downtime and cleaning frequency.



Product Parameters
Product Name Forming Fabric KRAFT SSB55208WM55NG
Material Polyester monofilament
Function Paper Machine
Application Light GSM Kraft Paper, Wrapping Paper, etc.
Technical SSB Triple Layer forming fabric
Width Customized
Weight Customized
Fabric Color Customized


Product Images
SSB Triple Layer Durable Paper Machine Fabric KRAFT SSB55208WM55NG-450CFM Fine Paper Side with Coarse Wear Side, High Internal Void Volume for Aggressive Dewatering SSB Triple Layer Durable Paper Machine Fabric KRAFT SSB55208WM55NG-450CFM Fine Paper Side with Coarse Wear Side, High Internal Void Volume for Aggressive Dewatering
Top Side View Bottom Side View

Application
Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
SSB Triple Layer Durable Paper Machine Fabric KRAFT SSB55208WM55NG-450CFM Fine Paper Side with Coarse Wear Side, High Internal Void Volume for Aggressive Dewatering SSB Triple Layer Durable Paper Machine Fabric KRAFT SSB55208WM55NG-450CFM Fine Paper Side with Coarse Wear Side, High Internal Void Volume for Aggressive Dewatering
