SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life
SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life
SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life
SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life
Specifications
Brand Name :
ATMC
MOQ :
1pc
Price :
inquiry
Payment Terms :
L/C,D/A,D/P,T/T
Delivery Time :
5-8 working weeks
Packaging Details :
Standard export ply-wood case
Structure :
/
Pattern Description :
/
Mesh × Count (l/cm) :
/
Warp Diameter (mm) :
/
Weft Diameter (mm) :
/
Warp Material :
/
Air Permeability :
/
Caliper (mm) :
/
Elongation(50N/cm) :
/
Break Strength :
/
Fiber Support Index (FSI) :
/
Drainage Index (DI) :
/
Open Area :
/
Fabric Color :
/
Description
SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life

Designed as a standard SSB triple layer fabric, KRAFT SSB50210WC45 utilizes a two‑shed paper side and a ten‑shed wear side. The fine paper side ensures even profiles and good fiber support for consistent sheet formation. On the wear side, long floats paired with a 3:2 CD shute ratio (forming to wear) accommodate medium and coarse CD yarns, thereby improving wear life and machine direction stability. Two MD thread systems enhance overall fabric rigidity. The open structure offers high dewatering capacity and easy showering, reducing downtime for cleaning. This fabric delivers an excellent balance of sheet support, drainage, and wear potential for modern paper making operations.


Key Features
  • Consistent fiber support reduces sheet marking risks.
  • Open structure allows high dewatering capacity.
  • Open weave design facilitates easy showering and cleaning.



Product Parameters
Product Name Forming Fabric KRAFT SSB50210WC
Material Polyester monofilament
Function Paper Machine
Application Light GSM Kraft Paper, Wrapping Paper, etc.
Technical SSB Triple Layer forming fabric
Width Customized
Weight Customized
Fabric Color Customized
Product Images
SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life
Top Side View Bottom Side View
Application
Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life
