SSB Triple Layer Paper Machine Cloth KRAFT SSB50210WM52-400CFM: Fine Forming Side & Long Float Wear Side for Uniform Formation and Easy Showering
SSB Triple Layer Paper Machine Cloth KRAFT SSB50210WM52-400CFM: Fine Forming Side & Long Float Wear Side for Uniform Formation and Easy Showering
SSB Triple Layer Paper Machine Cloth KRAFT SSB50210WM52-400CFM: Fine Forming Side & Long Float Wear Side for Uniform Formation and Easy Showering
SSB Triple Layer Paper Machine Cloth KRAFT SSB50210WM52-400CFM: Fine Forming Side & Long Float Wear Side for Uniform Formation and Easy Showering
Specifications
Brand Name :
ATMC
MOQ :
1pc
Price :
inquiry
Payment Terms :
L/C,D/A,D/P,T/T
Delivery Time :
5-8 working weeks
Packaging Details :
Standard export ply-wood case
Structure :
/
Pattern Description :
/
Mesh × Count (l/cm) :
/
Warp Diameter (mm) :
/
Weft Diameter (mm) :
/
Warp Material :
/
Air Permeability :
/
Caliper (mm) :
/
Elongation(50N/cm) :
/
Break Strength :
/
Fiber Support Index (FSI) :
/
Drainage Index (DI) :
/
Open Area :
/
Fabric Color :
/
Description
SSB Triple Layer Paper Machine Cloth KRAFT SSB50210WM52-400CFM: Fine Forming Side & Long Float Wear Side for Uniform Formation and Easy Showering

Engineered for optimal performance, the KRAFT SSB50210WM52-400CFM features a two‑shed over ten‑shed shute binding design in a triple layer configuration. Its fine forming side delivers even surface profiles and consistent fiber support, while the wear side incorporates long floats with a 3:2 CD shute ratio between forming and wear layers. This ratio enables the integration of medium and coarse CD yarns on the wear side, enhancing wear resistance and machine direction stability. The fabric’s dual MD thread system ensures high cross‑directional rigidity. Additionally, the open structure facilitates rapid water removal and simplifies cleaning, extending service life in high‑speed paper making applications.


Key Features
  • Fine forming side improves formation consistency.
  • Two MD thread systems deliver stable fabric construction.
  • High CD stability minimizes fabric distortion during operation.



Product Parameters
Product Name Forming Fabric KRAFT SSB50210WM
Material Polyester monofilament
Function Paper Machine
Application Light GSM Kraft Paper, Wrapping Paper, etc.
Technical SSB Triple Layer forming fabric
Width Customized
Weight Customized
Fabric Color Customized
Product Images
SSB Triple Layer Paper Machine Cloth KRAFT SSB50210WM52-400CFM: Fine Forming Side & Long Float Wear Side for Uniform Formation and Easy Showering SSB Triple Layer Paper Machine Cloth KRAFT SSB50210WM52-400CFM: Fine Forming Side & Long Float Wear Side for Uniform Formation and Easy Showering
Top Side View Bottom Side View
Application
Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
SSB Triple Layer Paper Machine Cloth KRAFT SSB50210WM52-400CFM: Fine Forming Side & Long Float Wear Side for Uniform Formation and Easy Showering SSB Triple Layer Paper Machine Cloth KRAFT SSB50210WM52-400CFM: Fine Forming Side & Long Float Wear Side for Uniform Formation and Easy Showering
