Specifications
Brand Name :
HKT-Robot
Model Number :
HKTZL150-400-200
Place of Origin :
China
Certification :
CE
MOQ :
1
Price :
Negotiable
Packaging Details :
Carton
Delivery Time :
1-4weeks
Payment Terms :
T/T
Product Name :
AGV Drive Wheel
Series :
HKTZL 150
Servo Driver :
FL6D1Z1-A00
Polyurethane bearing :
450kg
Wheel Width :
45mm
Hub Diameter :
150mm
Outside Diameter of Wheel :
200mm
Rated torque :
1.27Nm
Description

High Load Polyurethane Bearing AGV Hub Reducer for AGV Robot

Product Description:

HKTZL 150 AGV Drive Wheel is a robust, reliable and cost effective product that is designed for AGV applications. It features a 150mm hub diameter and a 450kg polyurethane bearing, providing a powerful yet efficient drive system. With a rated torque of 1.27Nm, it is perfect for many AGV applications. It is a great choice for hub transmission for AGV, AGV wheel hub gearbox and hub transmission for AGV.

HKTZL 150 AGV Drive Wheel is designed for maximum performance and long-term reliability. It is made from high quality materials and components, ensuring maximum durability and strength. It is easy to install and can be customized to meet specific requirements. It is also lightweight, making it suitable for a wide range of applications.

Features:

1.Walking reducers are ideal for robots and machinery systems, offering a great combination of reduction, torque and size.

2.They provide a significant gear reduction, converting a high-speed, low-torque motor input into low-speed, high-torque output that is suitable for leg or wheel movement. This makes them adept at moving heavy loads and navigating challenging terrain, as their design is built to handle high torque loads.

3.Their compact and lightweight design means they are practically made for integration into various mechanical systems.

Technical Parameters:

AGV Drive Wheel:

Parameter Specification
Model Number HKTZL150-400-200
Servo Driver FL6D1Z1-A00
Rated torque 1.27Nm
Polyurethane bearing 450kg
Hub Diameter 150mm
Wheel Width 45mm
Outside Diameter of Wheel 200mm
Series HKTZL 150

Low Voltage Servo Drive:

Parameter Specification
Model Number FL6D1Z1-A00
Supply Voltage 24-60VDC
Power 400W
Rated Current 11A
Peak Current 33A
Encoder Absolute and Incremental Encoder
Communication Protocol CANopen Modbus/RS485
Installation Aperture 5mm
Overall Dimensions 147*77*30mm
Weights 350g
