Specifications
Brand Name :
HKT-Robot
Model Number :
HKTZL95-400-140
Place of Origin :
China
Certification :
CE
MOQ :
1
Price :
Negotiable
Packaging Details :
Carton
Delivery Time :
1-4weeks
Payment Terms :
T/T
Series :
HKTZL 95
Rated torque :
1.27Nm
Polyurethane bearing :
300kg
Wheel Width :
40mm
Servo Driver :
FL6D1Z1-A00
Outside Diameter of Wheel :
140mm
Product Name :
AGV Drive Wheel
Hub Diameter :
95mm
Description

AGV Wheel Hub Gearbox with Polyurethane Bearing 300kg Series HKTZL 95

Product Description:

The AGV Drive Wheel – HKTZL 95 is a high-performance hub transmission used for AGV applications. It is designed to provide reliable and durable performance. It features a polyurethane bearing with a maximum load capacity of 300kg, and a wheel width of 40mm. It also comes with a servo driver – FL6D1Z1-A00 – for precise operation.

Features:

1.Gear Reduction for High Torque Output:Walking reducers are engineered to provide substantial gear reduction. This means they can take the high-speed, low-torque output from a motor and convert it into low-speed, high-torque output. This transformation is particularly useful for applications like leg and wheel movement, where high torque is needed for tasks like lifting or propelling heavy loads.


2.High Torque Handling:Walking reducers are built to withstand and handle significant torque loads. This makes them indispensable in scenarios where there's a requirement for lifting heavy objects or traversing through challenging terrains. The ability to handle high torque ensures reliability and stability in demanding environments.


3.Compact and Lightweight Design:Walking reducers are typically designed with compactness and lightness in mind. This allows them to be integrated into a wide range of robotic and machinery systems without adding unnecessary bulk or weight. This is especially important in applications where space constraints or weight limitations are a consideration.

Technical Parameters:

AGV Drive Wheel:

Parameter Specification
Model Number HKTZL95-400-140
Series HKTZL 95
Outside Diameter of Wheel 140mm
Servo Driver FL6D1Z1-A00
Rated torque 1.27Nm
Hub Diameter 95mm
Wheel Width 40mm
Polyurethane bearing 300kg

Low Voltage Servo Drive:

Parameter Specification
Model Number FL6D1Z1-A00
Supply Voltage 24-60VDC
Power 400W
Rated Current 11A
Peak Current 33A
Encoder Absolute and Incremental Encoder
Communication Protocol CANopen Modbus/RS485
Installation Aperture 5mm
Overall Dimensions 147*77*30mm
Weights 350g
