Specifications
warranty :
3 years
customized support :
OEM, ODM
Brand Name :
OCEAN PUMP
Model Number :
T
Place of Origin :
China
application :
Commercial Buildings
power source :
Diesel Engine OR ELECTRICAL MOTOR
pressure :
High Pressure
structure :
Single-stage Pump
voltage :
Other
Product name :
self priming sewage trash pump
Feature :
High Efficiency
Application :
Construction | Industrial | Municipal | Mining
Material :
cast iron
Model :
T-6
Advantage :
Long Working Life
Certification :
CE/ISO9001
Shipping :
Sea
Capacity :
330M3/H
HEAD :
25M
Description
Products Description
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump

Product Application

T series self suction sewage pump, self suction drainage pump unit and diesel engine mobile trailer are new international self suction sewage units. The utility model is suitable for outdoor use. The utility model has the advantages of high self suction, no blockage, convenient movement and simple operation without the power supply of the city power supply and the sewage impurities.

TECHNICAL SPECIFICATION OF T-6 MOVABLE DRAINAGE UNIT




T-6 PUMP
Max Flow
325m3/h
Max Head
32m
Max Solide
76.2mm (3'')
Self-priming
7.6m
Impeller dia
314.32mm
R.P.M
1500rpm


Material
Pump casing
Cast iron HT250
Impeller
Nodular cast iron
Shaft
40CR




Engine
Model
D226B-3D
No. of cylinders
3
Cooling method
water-cooling
Speed control type
Mechanical speed regulation
Start-up mode
DC start, and equipped with silicon rectifier charging generator
Total engine displacement
3.12L


Trailer
Tyre
2pcs
Support foot
4pcs
Tank capacity
80L
load
2000KG
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump

Main Features

1. Easy to install and easy to operate, in the control cabinet display period, you can directly view the pump and diesel engine operating parameters
2. Sewage capacity is large, the maximum amount of impurities through 76.2mm
3. Strong self-priming capacity, up to 7.6 meters
4. Design user-friendly, quick to the debris port, the fastest speed can troubleshoot.
5. When the equipment is out of order, the control cabinet will alarm automatically and show the cause of the trouble. Ensure safe operation of equipment.

Detailed Images
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump

Machine Parts

Name: Diesel engine

Brand: deutz

Original: China

Inline, 3 cylinder, four stroke, self suction, direct injection fuel system

Main Features

Name: Control cabinet
Brand: OCEAN
Original: China
Control the starting and stopping of diesel engine, check the water temperature, oil temperature, oil pressure, speed of diesel engine, etc.. Multi language: English, Spanish, Chinese, Russian, Arabic, polish, etc.

Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump

Machine Parts

Name: Exclude sundries
Brand: OCEAN PUMP
Original: CHINA
Loosen the wrench on both sides to remove the blockage in the pump.

Main Features

Name: Mechanical seal
Brand: Burgmann
Original: Germany
The container type mechanical seal adopts wear-resistant alloy and fluorine rubber. The service life is long, and the replacement is convenient.

Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump
Our Service
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Application Scenarios
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump
Product classification
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump
Company Profile
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump
Exhibition
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump
Packing and transportation
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump
FAQ
Good Quality Self Priming Pump With Diesel Engine Dry Priming Sewage Pump
1. Who Are We? We are based in Zhejiang, China, start from 2015,sell to Domestic Market(70.00%),North America(8.00%),South America(5.00%),Oceania(5.00%),Mid East(5.00%),Southeast Asia(3.00%),Africa(2.00%),South Asia(2.00%). There are total about 51-100 people in our office. 2. How Can We Guarantee Quality? Always a pre-production sample before mass production; Always final Inspection before shipment; 3.What Can You Buy From Us? Diesel Engine Water Pump,Submersible Sewage Pump,Gear Pumps,Chemical Pump,Self Priming Pump 4. Why Should You Buy From Us Not From Other Suppliers? Zhejiang Ocean Pump Co., Ltd supply pump widely which used in chemical, petroleum, pharmaceutical, electroplating, environmental protection, printing and dyeing, food and other industries. The company has a professional technical team, R & D. 5. What Services Can We Provide?
Accepted Delivery Terms: FOB,CIF,Express Delivery； Accepted Payment Currency:USD,EUR,CNY; Accepted Payment Type: T/T,L/C; Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
