Specifications
Brand Name :
GCL
Model Number :
Gposter B
Certification :
EMC/CE/ROHS/CCC/FCC/BIS
Place of Origin :
Guangdong, China
MOQ :
5
Price :
Price to be discussed
Supply Ability :
10000 Square Meter/Square Meters per Month
Packaging Details :
To protect the LED screen well during the long transportation :
1) If it's for rental use, we will pack all cabinets by flight cases;
2) If it's for fixed installation, we will pack all cabinets by plywood cases.
Application :
Outdoor, video play
Type :
LED
Color :
full color
Supplier Type :
Original manufacturer, ODM, OEM
Media Available :
Photo, Other, video
use :
advertising publish, retail store, shopping mall, display of dishes, self-service business, airport, subway, Restaurant & Hotel Supplies, medical treatment, street lamp, bus station
Pixel Pitch :
1.875mm
Specification :
Digital Poster
Brightness :
5500-6500nits,
IP Rating :
IP65, IP65
Resolution :
2K-4K
Total poster size :
H720"xW1440"xT101"(Customizable)
Usage :
Advertising LED Display
Refresh rate :
3840HZ
Installation :
fixed
Cabinet material :
Tempered Glass+Galvanlized Aluminim
IP rate :
IP65
Input Voltage :
AC100~240V (50 -63 HZ)
Description
Bus Stop, Airport Waiting Hall, Shopping Mall, Outdoor LED Energy-saving Waterproof Poster Screen P1.875mm
Product Overview

The Poster Led screen series is a high-performance outdoor grille LED display with excellent comprehensive performance, widely applied in commercial advertising and creative display scenarios. It adopts professional industrial protection technology and optimized structural design to deliver stable, high-definition and energy-efficient display effects.

Key Features
  • Advanced Protection: IP65 front module protection with IP54 cabinet rating, featuring three-proof paint technology for collision resistance, shock resistance, moisture proof, waterproof, dustproof, fire resistance, anti-static and smoke resistance
  • Efficient Heat Dissipation: Dual-side ventilation channel design accelerates air circulation and prevents overheating failures
  • Energy Efficient: High brightness of 3500 nits with average power consumption of only 240W
  • Precision Alignment: X and Y-axis four-direction adjustment technology for seamless display without visible gaps
  • Custom Sizing: Flexible dimensions with standard sizes of 720*1440*101mm and 960*1440*101mm, plus personalized customization
  • Superior Image Quality: Ultra-high refresh rate and true HDR dynamic restoration technology for rich picture layers and strong stereoscopic perception
Technical Specifications
Parameter P1.875 P4 P6 P8
Pixel Pitch (mm) 1.875 4 6 8
Pixel Density (dot/㎡) 284090 62500 27777 15625
LED Type 3in1 SMD1415 SMD1921 SMD3535 SMD3535
Scanning 8S 8S 8S 4S
Module Size (mm) 256*128 256*128 256*128 256*128
Cabinet Size (mm) Customized
Cabinet Weight (±0.25Kg) 40kg/㎡
Cabinet Resolution (PX* PX) Customized
Cabinet Material Steel (or Aluminum)
Brightness (CD/m²) 5500~6500
Maximum Power Consumption (w/sqm) 720
Average Power Consumption (w/sqm) 240
Horizontal Viewing Angle (Deg) 140°
Vertical Viewing Angle (Deg) 140°
Grey Scale(bit) 16
Refresh Rate (Hz) 1920-3840Hz
Input Voltage (V) 110-240V
Input Frequency (Hz) 60
Storage Temperature (℃) ﹣40℃－﹢80℃
Working Temperature(℃) ﹣20℃－﹢65℃
Working Humidity (RH) 95%
Cabinet Curve Outward & Inward
Waterproof Level IP65
Working Environment Outdoor
Installation Type Fixed installation
