Smart Modules and Intelligent Monitoring
The smart module design supports calibration coefficient storage and allows for temperature and voltage monitoring. It can accurately identify display fault points through port signal analysis.
Comprehensive Installation and Maintenance Design
Supports both front and rear installation and maintenance. The independent modular design allows for easy front and rear access to modules, power supplies, and receiving cards for maintenance.
Curve & 90° Angle Solution
Can be curved or configured with 90° outer angles, highly customizable based on project requirements, and widely utilized in outdoor naked-eye 3D commercial advertising design.
Dual Voltage Power Supply for High Brightness and Energy Efficiency
The product features a dual voltage power supply for enhanced energy efficiency, utilizing branded gold wire LEDs with a brightness of 10,000 cd/m² and a power consumption of ≤330 W/m².
| Porduct | P5.71 | P6.67 | P8 | P10 | P10D |
| Pitch | 5.71mm | 6.67mm | 8mm | 10mm | 10mm |
| Cabinet Size | W960*H960*T78mm | W960*H960*T83mm | |||
| Module Size | 480*320mm | ||||
| Cabinet Weight | 30kg | 29.54kg | 29.48kg | 29.42kg | 38.84kg |
| Cabinet Maintenance | Front & Rear Service | ||||
