25mm Glass Cloth Insulation Tape H Class 220℃ Thermal Rating
25mm Glass Cloth Insulation Tape H Class 220℃ Thermal Rating
25mm Glass Cloth Insulation Tape H Class 220℃ Thermal Rating
25mm Glass Cloth Insulation Tape H Class 220℃ Thermal Rating
25mm Glass Cloth Insulation Tape H Class 220℃ Thermal Rating
25mm Glass Cloth Insulation Tape H Class 220℃ Thermal Rating
25mm Glass Cloth Insulation Tape H Class 220℃ Thermal Rating
25mm Glass Cloth Insulation Tape H Class 220℃ Thermal Rating
Specifications
Volatile content :
≤2
Breaking Strenth :
≥250N/10mm X100mm
Width :
25mm
Soluble resin conten :
≥90%
Thickness :
0.30mm
Application :
Electrical Insulation
Resin content :
26±2 %
thermal class :
H Class 220℃
Brand Name :
UN.TEX
Place of Origin :
China
MOQ :
10000m
Price :
quoted as per size and quantity
Payment Terms :
L/C,T/T
Supply Ability :
10000rolls per month
Delivery Time :
about 35 days
Packaging Details :
cartons and pallet
Description
Durable Polyester Resin Impregnated Glass Banding Tape With Superior Electrical Insulation
Polyester resin impregnated glass banding tape is a high-performance industrial tape characterized by its exceptional mechanical strength, excellent electrical insulation properties, and outstanding chemical resistance.
Key Features
  • Delivers superior electrical insulation and exceptional heat resistance
  • Capable of withstanding extreme temperatures and high voltage
  • Designed for durability and long-term reliability
  • Suitable for use as Glass Cloth Insulant Tape or Glass Cloth Barrier Tape
Technical Specifications
Product Name: Resin Impregnated Weftless Banding Tape
Application: Electrical Insulation
Width: 25mm
Soluble Resin Content: ≥90%
Thermal Class: H Class 220℃
Thickness: 0.30mm
Material: Unsaturated Polyester Resin + E-glassfiber
Resin Content: 26±2%
Breaking Strength: ≥250N/10mm X100mm
Dielectric Strength: ≥12KV/mm
Primary Applications
  • Electric Motor & Transformer Manufacturing:
    • Motors: Used for binding and securing the copper windings on motor rotors to prevent them from spreading or deforming under centrifugal force at high speeds
    • Transformers: Used for binding and securing transformer cores and coils, enhancing overall structural strength and improving the insulation class
  • Pipe, Cable & Joint Repair & Sealing:
    • Used to repair cracks and leaks in metal or composite pipes in industries such as oil, chemical, and water supply
    • Used for the insulating sealing and protection of cable joints, creating a sturdy, waterproof outer sleeve
  • Sports Equipment & Industrial Product Reinforcement:
    • Used to reinforce grips or connections on sporting goods like fishing rods, golf clubs, and bows
    • Used for local reinforcement of wood products, plastic, or metal tools to increase their durability
Packaging & Shipping Information
Product Packaging: The Glass Cloth Insulation Tape is supplied in convenient roll form, each measuring 50mm in width and 33m in length. Each roll is wound around a robust cardboard core to ensure integrity during shipping and storage.
Shipping: Securely packed in reinforced cardboard boxes with protective padding. Standard delivery within 5-7 business days, with expedited shipping options available.
