SAE F-5 Felt Seal With Good Resilience And Wear Resistance
SAE F-5 Felt Seal With Good Resilience And Wear Resistance
SAE F-5 Felt Seal With Good Resilience And Wear Resistance
SAE F-5 Felt Seal With Good Resilience And Wear Resistance
SAE F-5 Felt Seal With Good Resilience And Wear Resistance
SAE F-5 Felt Seal With Good Resilience And Wear Resistance
Specifications
Brand Name :
UN.Tex
Place of Origin :
China
Price :
based on size and quantity
Payment Terms :
T/T
Delivery Time :
about 15 days
Packaging Details :
Cartons and pallets
Total Thickness :
1" ± 0.3mm
Initial tack :
40 mm/14#
180°Peel Strength :
420 g/25mm
Breakdown Voltage :
6000 V
Longitudinal Tensile Strength :
5.78 Kgf/25mm
Transverse Tensile Strength :
5.03 Kgf/25mm
Longitudinal Elongation :
170%
Lateral Elongation :
155%
Density :
0.26±0.03 g/cm3
Rupture Strength :
≥ 255 N/cm2
Temperature :
≤ 200 ℃
Color :
Natural White
Standard :
SAE F-5
Description
SAE F-5 Felt Seal With Good Resilience And Wear Resistance
Product Overview

White precision felt seal is made of high-quality wool fibers through a pressed felt process, conforming to the SAE F-5 medium-density grade standard. Its structure is dense and uniform, with good resilience and wear resistance. It is specifically designed for dust prevention, sealing, and oil retention/lubrication in precision mechanical equipment.

Technical Parameters
Parameter Value
Total Thickness 1"
Temperature ≤ 200℃
Key Advantages
  • Dust sealing: The medium-density structure effectively blocks dust without affecting smooth movement.
  • Oil retention & self-lubrication: Absorbs and slowly releases oil, reducing friction and wear.
  • Clean & lint-free: White pressed felt with firmly bonded fibers, suitable for clean environments.
Applications
  • Dust sealing for precision bearings and spindle units.
  • Lubrication and wiping for guide rails and lead screws in automation equipment.
  • Shaft sealing in office equipment such as printers and copiers.
