F Class Aramid Fiber Paper Tape High Temperature Resistant Tape
F Class Aramid Fiber Paper Tape High Temperature Resistant Tape
F Class Aramid Fiber Paper Tape High Temperature Resistant Tape
F Class Aramid Fiber Paper Tape High Temperature Resistant Tape
F Class Aramid Fiber Paper Tape High Temperature Resistant Tape
F Class Aramid Fiber Paper Tape High Temperature Resistant Tape
Specifications
Brand Name :
UNTEX
Model Number :
432
Place of Origin :
CHINA
Price :
based on size and quantity
Payment Terms :
T/T
Delivery Time :
about 25 days
Packaging Details :
cartons and pallets
Total thickness :
0.105±0.01mm
Aramid paper Thickness :
0.06±0.005mm
Adhesive type :
Flame Retardant Acrylic Pressure Sensitive Adhesive
Breakdown voltage :
≥1.8 kV
Tensile strength :
≥30 N/10mm
Elongation at break :
≥4%
Adhesion (to steel surface) :
≥12.0 N/25mm
Long-term temperature resistance :
F class/155℃
Description
F Class Aramid Fiber Paper Tape High Temperature Resistant Tape
Product Overview

This customized high temperature resistant tape is manufactured using polyaramid fiber paper, coated with flame retardant acrylic pressure sensitive adhesive on one side through high temperature processing. The product offers excellent temperature resistance (-55℃ to 155℃) and is suitable for F grade heat-resistant electrical and electronic insulation banding, motor and transformer coil insulation banding applications. It serves as an effective replacement for NOMEX tape in applications where mechanical strength requirements are not critical.

Technical Parameters
Parameter Value
Total Thickness 0.105mm
Long-term Temperature Resistance F class / 155℃
Key Advantages
  • Excellent thermal stability with F-class long-term heat resistance of 155℃
  • Soft and tear-resistant with strong cohesive force, resistant to deformation, suitable for adhesion protection on various profile surfaces
  • No adhesive residue when unwrapping after long-term high temperature curing
  • Ideal for tight and secure coil wrapping without tape end tilting
Applications
  • High-quality F-class motor and transformer coil end wrapping
  • Chemical corrosion resistant, suitable for insulating wrapping of high-energy lithium batteries and mobile phone accessory punching
  • Wrapping and insulating electronic coils for HVT, HID, and other electronic transformers
