Araldite® CW 1305 High Thermal Conductivity Explosion-Proof Epoxy Encapsulant System | 180℃ Certification

Product Simple Attributes

This system comprises Araldite® CW 1305 modified epoxy resin and Aradur® HY 1300 hardener, mixed at 100:11 weight ratio. Designed for explosion-proof electrical equipment, certified UL 94 V-0 (3.0mm) and EN 45545-2 railway fire standard (R23 HL2/R24 HL3).

Product Introduction

CW 1305/HY 5809is a solvent-free epoxy system with inorganic fillers, curable at RT or elevated temperatures. Optimized viscosity (3,500 mPa·s @40℃) enables vacuum casting, forming high-density insulation with 27 kV/mm dielectric strength and 10¹⁴ Ω·cm volume resistivity

Deepening of special attributes

Thermal Management​​: 0.88 W/mK conductivity with 180℃ UL rating (File E206297), CTE α1/α2=42/105 ppm/K
​​Flame Safety​​: UL 94 V-0 (3mm), LOI 36.1%, EN 45545-2 R24 HL3 compliant
Environmental Resistance​​: 0.04% water absorption (23℃/24h), 88 Shore D hardness

Application scenarios

​​Key Applications​​: Explosion-proof transformers (e.g. mining equipment), rail transit capacitors (EN 45545-2 R24 HL3 compliant), marine filters
​​Industry Case​​: Siemens Sitras 8 signaling devices (per Huntsman HT-9222) adopt this system for capacitor encapsulation at -40℃ to 155℃

1. Who are we?

We are Shenzhen Huazhisheng New Material Technology Co., Ltd., a professional industrial adhesives and sealants supplier based in China since 2018. we serve global markets: Mainland China (60%), Southeast Asia (20%), North America (10%), and Europe (10%).

2. What products do you offer?

we supply high-performance adhesives and sealants from global leaders including:

Cemedine, Dow Corning, Shin-Etsu, Araldite, and Momentive,etc.

3. How do you guarantee product quality?

Quality assurance through:

Mandatory pre-production samples approval

Final inspection by QC team before shipment

International certifications: SGS, UL, FDA, RoHS, REACH

4. Why choose us over other suppliers?

Reliable Supply:Authentic products from top manufacturers

Expert Support:Technical guidance for product selection

Global Compliance:Certifications meeting target market standards

Efficient Service:Customized solutions & professional support

5. What services do you provide?

Delivery​:EXW/FOB/CIF

Payment​:USD/EUR/CNY/HKD via T/T, L/C

Support​:Technical consultation & logistics coordination
