3M 5200 Marine Adhesive Sealant Waterline Bonding Solution For Boats
3M 5200 Marine Adhesive Sealant Waterline Bonding Solution For Boats
3M 5200 Marine Adhesive Sealant Waterline Bonding Solution For Boats
3M 5200 Marine Adhesive Sealant Waterline Bonding Solution For Boats
3M 5200 Marine Adhesive Sealant Waterline Bonding Solution For Boats
3M 5200 Marine Adhesive Sealant Waterline Bonding Solution For Boats
3M 5200 Marine Adhesive Sealant Waterline Bonding Solution For Boats
3M 5200 Marine Adhesive Sealant Waterline Bonding Solution For Boats
Specifications
Place of Origin :
USA
Price :
CN¥185.14/pieces >=1 pieces
Brand Name :
3M
Model Number :
3M 5200
Certification :
TDS,SDS,Rohs
Main Raw Material :
Silicone
Usage :
Transportation, Packing, Footwear & Leather, Fiber & Garment, Construction, Woodworking
Samples :
Free sample available
Color :
Clear
Application Method :
Caulking gun
Shelf Life :
12 months
Curing Time :
24 hours
Uv Resistance :
Yes
Material :
Silicone
Flexibility :
High
Temperature Resistance :
-60°C to 260°C
Classification :
Other Adhesives
Application :
polyimide tape or Polyester tape
Chemical Resistance :
Yes
Einecs No :
210-898-8
Other Names :
pressure sensitive adhesive
Type :
Adhesive
MOQ :
1
Packaging Details :
1 piece
Delivery Time :
5-8days
Payment Terms :
T/T,L/C,D/A,D/P,Western Union,MoneyGram
Supply Ability :
1000Piece
Description

3M 5200 Marine Adhesive Sealant: Superior Waterline Bonding Solution for Boats

​Product Basic Properties

3M 5200 is a single-component, moisture-curing polyurethane adhesive sealant designed for permanent bonding in marine environments. It offers high strength, flexibility, and resistance to saltwater, UV, and vibrations. Available in fast-cure (5200 FC) and slow-cure variants, it cures to form a waterproof seal that withstands submersion above and below the waterline. Standard packaging includes 295 mL tubes (12 tubes/box) or 88.7 mL sausages, with a shelf life of 24 months

​Product Introduction

3M 5200 is engineered for demanding marine applications, providing a durable and flexible bond between materials like wood, gel coat, fiberglass, and metals. Its unique polyurethane formulation reacts with moisture to create a resilient seal that absorbs stress from expansion, contraction, and impact. Ideal for both manufacturing and repair, it ensures long-term performance in harsh oceanic conditions

Special Properties

  1. Permanent Waterproofing​​: Forms a watertight barrier even under continuous submersion, resisting saltwater corrosion and hydrolysis
  2. ​​Stress Resilience​​: Maintains adhesion despite vibration, thermal expansion, or structural movement (elongation >900%, tensile strength ~600 psi)
  3. ​​Rapid & Slow-Cure Options​​:
    • Fast-Cure (FC): Tack-free in 1–2 hrs, full cure in 24–48 hrs
    • Slow-Cure: Tack-free in 48 hrs, full cure in 5–7 days
  4. ​​Certified Durability​​: Shore A hardness of 60, with 95% solid content ensuring no shrinkage

Application Scenarios

3M 5200 is critical for marine structural bonding and sealing:
​​Hull & Deck Seams​​: Seals fiberglass deck-to-hull joints against water ingress.
​​Through-Hull Fittings​​: Waterproofs penetrations for sensors, transducers, or plumbing.
​​Hardware Installation​​: Bonds windows, cleats, and motor mounts to fiberglass/wood substrates.
​​Below-Waterline Repairs​​: Permanently fixes propeller struts, keels, and rudder posts

​Technical Parameters

Property Value Test Standard
Form Medium-viscosity paste N/A
Cure Time (Fast-Cure) 1–2 hrs (tack-free), 24–48 hrs (full) ASTM D412
Shore Hardness 60 A ASTM D2240
Tensile Strength 600 psi ASTM D412
Elongation at Break >900% ASTM D412
Solid Content 95% Gravimetric
Operating Temp Range -54°C to +82°C MIL-S-23586C
Water Resistance Permanent submersion ISO 2812-2
Package Size 88.7 mL / 295 mL N/A

1. Who are we?

We are Shenzhen Huazhisheng New Material Technology Co., Ltd., a professional industrial adhesives and sealants supplier based in China since 2018. we serve global markets: Mainland China (60%), Southeast Asia (20%), North America (10%), and Europe (10%).

2. What products do you offer?

we supply high-performance adhesives and sealants from global leaders including:

Cemedine, Dow Corning, Shin-Etsu, Araldite, and Momentive,etc.

3. How do you guarantee product quality?

Quality assurance through:

Mandatory pre-production samples approval

Final inspection by QC team before shipment

International certifications: SGS, UL, FDA, RoHS, REACH

4. Why choose us over other suppliers?

Reliable Supply:Authentic products from top manufacturers

Expert Support:Technical guidance for product selection

Global Compliance:Certifications meeting target market standards

Efficient Service:Customized solutions & professional support

5. What services do you provide?

Delivery​:EXW/FOB/CIF

Payment​:USD/EUR/CNY/HKD via T/T, L/C

Support​:Technical consultation & logistics coordination
