AT350 pneumatic actuator single action SR pneumatic rotary actuator

Pneumatic Actuator

Pressure Range: Max. Working pressure 10bar

Air pressure: 2.5bar~8bar

Adjustment Range: 90°± 5°

Ambient temperature: -20 ~ +90° C

Type: Double acting, Single acting (spring return)

Optional accessories: Solenoid valve, limite switch, electric position, air regulator

Lubrication: All the moving parts are coated with lubricants, extending their service life

Life Time: One million time

Pneumatic actuator control valvesstatement of usage and selection

• Through research development and design XM series pneumatic actuators incorporate the latest technology materials and innovative idea. The product proudly boasts the following features.
• Full conformance to the latest specifications: ISO5211,DIN3337 and VDINDE-3854,NAMUR.

• The extruding high intensity aluminum body possesses a honed internal surface coated with hard anode oxygenation for long life. Low coefficient of friction and swift performance.

• Excellent compact and modernized construction along with multi specifications makes the selection both economic and beneficial.

• All acting surface adopt high quality bearing resulting in low friction, high cycle life, and no noise

• The two independent external stroke adjustment bolts can easily and precisely adjust ±5°at both open and close directions.

• Same outline actuators have the functional modes of double acting and single acting (Spring -Return). The Spring-Return has the normally-open and normally-close styles.

• Multi function indicator with NAMUR is convenient for mounting accessories.

• Pre-compressed load spring is convenient for safe mounting and tear down procedures.

• Die-casting aluminum pistons and end caps have high intensity and light weight.

• Different O-rings materials are available for high and low temperature.

• Solenoid valves are easily mounted without any connecting plank.
