48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
Acrel
Model Number :
AMC16Z-FDK48
MOQ :
1 Piece
Price :
$186.20 / Piece
Display Type :
none
Phase :
Three Phase
Measuring Energy Range :
0-999999.99Kwh
Accuracy Class :
Class 1
Output Voltage :
250V AC/30VDC
Operating Temperature :
-15℃~55℃
Dimensions :
180mm*94.3mm*75mm
Interface and communication :
RS485, Modbus-RTU
Measuring channels :
48 channels
Selling Units :
Single item
Single package size  :
18X9.43X7.5 cm
Single gross weight :
2.000 kg
Package Type :
It was packed in carton box, suitable for long way transportation.
Description
Products Description
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
AMC16Z-FDK48 Data Center Monitor Device
● Designed specifically for the power supply management of server in the data center
● A+B independent 24 circuits(48 in total)
● kWh Class 0.5
● DIN 35 mm
Function
• 24 channels of each circuit of A+B independent 2 circuits the outgoing current, active power, active power, reactive power
• 1 RS485 communication
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
Installation:
DIN rail 35mm

Dimension(L*W*H):
180*94.3*75mm
Reference voltage
220V
Voltage Accuracy
Class 0.2
Incoming line current
50mA
Current Accuracy
Class 0.5
Working power
DC12V/3W
Frequency
45~65Hz
Temperature
-15℃~55℃
Energy
0.5
Interface and communication
RS485, Modbus RTU
Humidity
≤95%(No condensation)
Auxiliary power supply
DC12~24V
Wiring
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
Typical connection
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
Company Profile
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
48 channels Single Phase Energy Monitoring Device For IDC AMC16-FDK48
