10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
Acrel
Model Number :
ATE100
Supply Ability :
8000 Piece/Pieces per Day
Packaging Details :
It is packed in a crash bag and then put into a cardboard box.
MOQ :
>=1 Pieces
Price :
$60.00
Display Type :
Analog Only
Phase :
Nothing
Measuring Energy Range :
nothing
Accuracy Class :
0.5
Output Voltage :
nothing
Operating Temperature :
-40℃~+125℃
Dimensions :
23*102*48mm
Wireless Frequency :
2.4GHz
Communication Distance :
10m in open area
Transmission Frequency :
4 min
Installation :
Bolted
Application :
Joints between bus bar and cable
humidity :
≤95%
Atmospheric pressure :
86kPa~106kPa
Temperature :
-40℃~125℃
Samping frequency :
25s
Certificate :
CE ISO9001
Port :
SHANGHAI
Description
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
ATE100 Wireless Temperature Sensor
● Wireless transmit,2.4GHz;
● Wireless transmission distance, 10 meters;
● Fast sampling frequency, 25s;
● Battery -powered, more than 5 years;
● Widely temperature measuring range, -40℃~+125℃.
ATE100 wireless temperature sensor has been developed in compliance with Specification for Wireless Temperature Measuring
equipment, NB/T 42086-2016. It is suitable for 3-35kV indoor switchgears, including built-in switchgears, handcart switchgears,
fixed switchgears and loop-net switchgears. It is also suitable for 0.4kV low-voltage switchgears such as fixed switchgears and
drawer switchgears.
Technical parameters
Item
Value
Wireless temperature measurement
Wireless frequency
2.4GHz
Communication distance
10m in open area
Sampling frequency
25s
Transmission frequency
4min
Power source
Battery
Installation
Bolted
Range of temperature
-40℃~125℃
Precision
±2℃
Application
Joints between bus bar and cable
Service life
＞5 years
Environmental requirement
Operating temperature
-40℃~125℃
Relative humidity
≤95%
Atmospheric pressure
86kPa~106kPa
APPEARANCE
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
Installation
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
Typical connection
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
Jiangsu Anke Ruiwei Grid Research Institute Co., Ltd., the manufacturer base located in Jiangyin, Wuxi City, is a pioneer
enterprise integrates the informatization and industrialization of Jiangsu province. It has a multiple function product test
center(CNAS certified), which can carry out a variety of tests on environment, electromagnetic compatibility, safety and
reliability. The production relies on the advanced information management system and strictly follow the ISO9001 management standard, which provide a guarantee for industrialization and large-scale implementation of the products. The annual capacity of the electrical meter is 2 million sets, 1.5 million power transformers and 10,000 sets of energy-saving cabinets.
Acrel Co.,Ltd.[stock code: 300286.sz] is a high-tech enterprise integrates R&D, production, sales and service, since its establishment, it committed to provide users with energy efficiency management and power security system solutions. Acrel Electric has a complete production line from cloud platform software to sensors. At present, more than 8,000 sets of various solutions are running all over the country, help users to realize the visual management of energy consumption, provide users the energy data services, and escort users an efficient and safe energy consumption.
10 Meters Transmission 2.4GHz Wireless Temperature Monitor Battery Powered
FAQ

1. Q: Where is your factory located ? How can I visit here ? Can your factory arrange transportation for me?

A: Our production base is located in Jiangyin City, Jiangsu Province, China; Which will take about 2 hours by car from Shanghai to our factory. We can arrange our driver to pick you up from your hotel when you arrive Shanghai.

2. Q: Does your factory have the design and development capabilities, can you factory accept customized products?

A: The staffs in our R&D department are well experienced in the Electric industry, with more than 10 years’ experience. We can make customized products especially for you; please kindly contact us for more

3. Q: How long could I get my order?

A: Stock Products: shipping within 5 days.
B: Customized products: usually 10-15 days. It depends on your design and quantity.

4. Q: How is your production management and quality control system?

A: All our product process follows up ISO9001. The strict implementation of ISO9001 assures to provide error–free products to our customers. We will show you these in our workshop during your visiting.

5. Q: How can I get a sample to check the quality?

A: We are glad to offer you samples for test. Leave us message of the item you want and your city address. We will offer you detail sample packing information, and select the best way to deliver it.
