IFM Inductive high-temperature sensor IG6119 IGA3008ZBPKG/5M/SH
IFM Inductive high-temperature sensor IG6119 IGA3008ZBPKG/5M/SH
IFM Inductive high-temperature sensor IG6119 IGA3008ZBPKG/5M/SH
IFM Inductive high-temperature sensor IG6119 IGA3008ZBPKG/5M/SH
IFM Inductive high-temperature sensor IG6119 IGA3008ZBPKG/5M/SH
IFM Inductive high-temperature sensor IG6119 IGA3008ZBPKG/5M/SH
IFM Inductive high-temperature sensor IG6119 IGA3008ZBPKG/5M/SH
IFM Inductive high-temperature sensor IG6119 IGA3008ZBPKG/5M/SH
Specifications
Brand Name :
IFM
Model Number :
IG6119
Place of Origin :
Germany
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100pcs per month
Delivery Time :
Negotiable
Packaging Details :
carton
Manufacturer :
IFM
Product No :
IG6119
Thread designation :
M18 x 1
Protection :
IP 65
Description

IFM Inductive high-temperature sensor IG6119 IGA3008ZBPKG/5M/SH


For use in temperatures up to 180 °C

For applications in the steel and glass industries

Sensor and evaluation unit in one housing

Robust stainless steel housing for use in harsh industrial environments

5 m silicone cable for termination outside high temperature environment



Electrical designPNP
Output functionnormally open
Sensing range[mm]8
HousingThreaded type
Dimensions[mm]M18 x 1 / L = 77

Application

Applicationhigh-temperature applications

Electrical data

Operating voltage[V]10...35 DC
Current consumption[mA]< 15
Protection classIII
Reverse polarity protectionyes

Outputs

Electrical designPNP
Output functionnormally open
Max. voltage drop switching output DC[V]2
Permanent current rating of switching output DC[mA]150
Switching frequency DC[Hz]400
Short-circuit proofyes
Overload protectionyes

Monitoring range

Sensing range[mm]8
Operating distance[mm]0...6.5

Accuracy / deviations

Correction factorstainless steel: 0.6 / brass: 0.3 / aluminum: 0.2 / copper: 0.1
Hysteresis[% of Sr]3...15
Switch-point drift[% of Sr]-15...15

Operating conditions

Ambient temperature[°C]0...180
ProtectionIP 65

Tests / approvals

EMCEN 61000-4-2 ESD2 kV CD / 4 kV ADEN 61000-4-3 HF radiated3 V/mEN 61000-4-4 Burst2 kVEN 61000-4-6 HF conducted3 V
MTTF[years]683

Mechanical data

Weight[g]262.5
HousingThreaded type
Mountingnon-flush mountable
Dimensions[mm]M18 x 1 / L = 77
Thread designationM18 x 1
Materialthreaded sleeve: stainless steel; sensing face: LCP

Accessories

Items suppliedlock nuts: 2

Remarks

Pack quantity1 pcs.

Electrical connection

ConnectionCable: 5 m, silicone; highly flexible; 3 x 0.22 mm²





IFM Inductive high-temperature sensor IG6119 IGA3008ZBPKG/5M/SH
