WAGO 750-616 Compact Distance Module for WAGO-I/O-SYSTEM

Specifications

Analog Outputs :

Special Features :

Integrated TwinCAT 3 runtime environment

Discount Schedule :

0I12

Interface :

NAMUR

Brand Name :

Norgren

Model Number :

750-616

Certification :

ATEX

Place of Origin :

MOQ :

Price :

Negotiate

Payment Terms :

T/T,Alipay,Paypal

Supply Ability :

100pcs per month

Packaging Details :

carton

Condition :

New Original with Sealed

Connection :

Connector, M16x0.75, 8-pin

Input Voltage :

24V DC

Description

WAGO 750-616 Compact Distance Module for WAGO-I/O-SYSTEM

Product Details:
Manufacturer :WAGO

Product No : 750-616

https://www.achievers-automation.com More Products

Reliable Industrial Component Sourcing for Enterprises

This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.

To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.

The WAGO 750-616 is a high-quality compact distance module designed exclusively for the WAGO-I/O-SYSTEM, serving as a critical spacing component in modular industrial control setups. Engineered to WAGO’s rigorous standards, this light gray distance module enables flexible arrangement of I/O modules on DIN rails, optimizing cabinet space utilization while ensuring compatibility with the entire WAGO 750 series ecosystem. With robust polycarbonate and polyamide 6.6 housing, it delivers exceptional durability and compliance with marine and industrial EMC standards, making it ideal for marine automation, industrial control cabinets, and harsh environment applications.

Detail:

Parameter Category	Specifications
Manufacturer & Product Line	WAGO, WAGO-I/O-SYSTEM Series (Distance Module)
Product Type	Compact Distance Module
Power Supply	System supply: 5 VDC, supplied via data contacts
Wire Compatibility	Copper (Cu) conductor materials
Certifications & Standards	ATEX, UL 121201/UL 508, DNV, ABS, Lloyd's Register, RoHS compliant; EMC: EN 61000-6-2 (immunity), EN 61000-6-4 (emission)
Housing Material	Polycarbonate + Polyamide 6.6; Light gray color
Fire Load	1.107 MJ
Pollution Degree	2, compliant with IEC 61131-2 standard

Characteristic Type	Details
Operating Temperature Range	0°C to +55°C
Storage Temperature Range	-40°C to +85°C
Humidity Tolerance	Up to 95% RH (non-condensing); 75% RH with H2S (10ppm) and SO2 (25ppm) tolerance
Operating Altitude	0m to 2000m above sea level (6562 ft)
Protection Rating	IP20 (suitable for cabinet-mounted installation)
Mechanical Dimensions	Width: 12mm (0.472 inches); Height: 100mm (3.937 inches); Depth: 69.8mm (2.748 inches); Depth from DIN rail upper edge: 62.6mm (2.465 inches)
Installation & Weight	35mm DIN rail mounting; Multiple orientations (horizontal/vertical); Weight: 36g
Vibration & Shock Resistance	Vibration: 4g (IEC 60068-2-6); Shock: 15g (IEC 60068-2-27); Corrosion resistance: IEC 60068-2-42/43
