Phoenix Contact QUINT4-PS1AC/2X15DC/2/PT 2904596 PT Power Supply

Specifications

Packaging Details :

carton

Input Voltage :

5V ± 5% (from PC USB port)

Ph Measuring System :

For FLXA402, PH202, FLXA202, FLXA21 (*2)

Integral Indicator :

Digital indicato

Place of Origin :

MOQ :

Contact Input :

Two points

Price :

Negotiable

Connecting Cable :

KS1 KS2

Supply Ability :

1000pcs per week

Surface :

SMS01

Payment Terms :

T/T

Brand Name :

Phoenix Contact

Protection Level :

IP54

Model Number :

2904596

Cell Constant :

0.05 cm-1, 5 cm-1

Certification :

HART

Description

Phoenix Contact QUINT4-PS1AC/2X15DC/2/PT 2904596 PT Power Supply

Product Details:

Manufacturer : Phoenix Contact

Product No. : 2904596

https://www.achievers-automation.com More Products

Reliable Industrial Component Sourcing for Enterprises

This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.

To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.

ThePhoenix Contact QUINT4-PS1AC/2X15DC/2/PT is a high-efficiency, single-phase switched-mode power supply designed for reliable power distribution in industrial automation systems. As a core product in Phoenix Contact’s QUINT4 product family, it delivers stable dual ±15V DC output with exceptional performance, combining compact design with robust protection features. This power supply is specifically engineered for DIN rail mounting, ensuring seamless integration into control cabinets across diverse industrial sectors while maintaining consistent operation in harsh environmental conditions — a key advantage for businesses seeking long-term reliability in critical automation setups.

Detail:

Specification Category	Details
Product Type	Switched-Mode Power Supply (SMPS)
Product Family	QUINT4
Manufacturer	Phoenix Contact
Product Model	QUINT4-PS1AC/2X15DC/2/PT
Mounting Type	DIN Rail (NS 35/7.5)
Input Type	Single-Phase AC / DC
Nominal Output Voltage	±15V DC (Dual Output)
Connection Method	Push-In Connections
Operating Temperature Range	-25°C to +70°C
Degree of Protection	IP20
Flammability Rating (Housing)	UL 94 V0
Dimensions (W×H×D)	36 mm × 124 mm × 120 mm

Performance Parameter	Value
AC Input Voltage Range	100V AC – 240V AC (-15% to +10%)
DC Input Voltage Range	110V DC – 250V DC (-20% to +10%)
Nominal Output Current	2A (+15V DC); 1.4A (-15V DC)
Static Boost Current	2.5A (+15V DC, ≤40°C)
Dynamic Boost Current	4A (+15V DC, ≤60°C, 5s)
Typical Efficiency	88.8% (120V AC); 89.4% (230V AC)
Output Ripple	≤60 mVpp (at nominal values)
Test Voltage (Input/Output)	4 kV AC (50 Hz, 1 min)
Overvoltage Protection (OVP)	≤18V DC (output)
Line Regulation	<0.1% (±10% input voltage change)
Load Regulation (Static)	<0.5% (10% to 90% load change)
Maximum Power Dissipation	<6.6W (120V AC); <6.1W (230V AC)
