E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch
E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch
E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch
E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch
E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch
E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch
Specifications
Place of Origin :
DE
Display :
LCD display, backlight optional
Monitoring Loop Quantity :
4~8 loops (configurable)
Operating Humidity Range :
10%~90% RH (non-condensing)
Certification :
ATEX
MOQ :
1
Payment Terms :
T/T,Allipay,paypal
Packaging Details :
carton
Protection Rating :
IP20 (panel-mounted)
Delivery Time :
12-18 weeks
Input Signal :
AC current: 0~5A; AC voltage: 0~450V
Communication Protocol :
Modbus RTU (RS-485)
Model Number :
FTL33-1369/0
Measurement Accuracy :
Current: ±0.5% FS; Voltage: ±0.5% FS
Brand Name :
E+H
Supply Ability :
100pcs per month
Price :
Negotiable
Description

E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch


Product Details:

Manufacturer : Endress+Hauser

Product No. :FTL33-1369/0

https://www.achievers-automation.com More Products


This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.

To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.


The E+H FTL33-1369/0 belongs to Endress+Hauser Liquiphant FTL33 sanitary vibronic tuning fork series, adopting piezoelectric resonant frequency shift measurement principle for reliable point-level detection of homogeneous liquid medium with minimum density ≥0.7 g/cm³ (custom ≥0.5 g/cm³ optional). This specific 1369/0 variant is equipped with standard Tri-Clamp DN25~DN38 hygienic clamping process connection, dual 3-wire PNP switching + IO-Link digital communication output, full 1.4404 (AISI316L stainless steel) wetted components and seamless stainless steel housing complying with food sanitary standard, supporting CIP/SIP high-temperature on-site cleaning for food, beverage and pharmaceutical production lines. Built-in continuous electronic self-diagnosis circuit monitors tuning fork operating status in real time to eliminate false triggering caused by component aging or damage; plug-and-play installation without on-site calibration required, measurement performance remains stable against liquid foam, medium adhesion, pipeline turbulence and fluid conductivity fluctuation. Mainly applied for tank overflow prevention and pump dry-run protection in sanitary-grade fluid processing industries.

Detail:

Parameter Item Standard Technical Specification
Full Model Code FTL33-1369/0 (E+H Liquiphant FTL33 Sanitary Series)
Measuring Principle Vibronic tuning fork resonant frequency variation detection
Minimum Detectable Medium Density ≥0.7 g/cm³; custom option ≥0.5 g/cm³ available
Output Configuration 3-wire DC PNP switch + IO-Link digital communication
Rated Operating Power Supply DC 10 V ~ 30 V
Max PNP Switch Load Current 200 mA
Onboard Core Function Full electronic self-monitoring + local LED working status indicator
Adjustable Switch Delay Configurable 0.5s~10s via IO-Link parameter programming
On-site Test Feature External magnetic test point for non-disassembly function inspection


Spec Classification Detailed Parameter Data
Wetted Tuning Fork Material 1.4404 / AISI316L stainless steel
Standard Process Connection Sanitary Tri-Clamp DN25~DN38
Housing Material Solid seamless 316L stainless steel
Ingress Protection Grade IP67, optional IP69K for high-pressure washdown
Ambient Working Temperature -40°C ~ +70°C (-40°F ~ +158°F)
Allowed Process Medium Temperature -40°C ~ +150°C (-40°F ~ +302°F)
Absolute Process Pressure Range Full vacuum ~ 40 bar abs (0~580 PSI maximum overpressure)
Wetted Surface Roughness Ra 0.76μm sanitary finish for food contact
Sanitary Certification FDA, 3A compliant, EN10204-3.1 material test certificate

E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch




Brand

E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch

E+H is a global leader in providing measurement instruments, services, and solutions for the process and laboratory industries. Since its founding in 1953, the company has been committed to enhancing production efficiency, safety, and sustainability through innovative technologies. E+H’s product portfolio covers a wide range of areas, including flow measurement, level measurement, pressure and temperature measurement, analytical instrumentation, and data management. Its solutions are widely used in industries such as chemicals, food and beverage, oil and gas, power generation, and water and wastewater treatment.



Company Introduction:

E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch

Achievers Automation Limited has more than 10 years experience in the market of Industrial Automation, specialized in reselling factory sealed Probe, Sensor, DCS,isolator barrier, HMI, PLC,Adapter,Profibus connector and cable from Brands as BENTLY NEVADA, E+H, MTL, AB, , YOKOGAWA, ASCO, Schneider, Lenze, Pro-face, Mitsubishi, Omron, Lenze, Delta, IFM etc. If you have any request, please do not hesitate to contact us.

E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch

Below are the TOP BRANDS we handle in the past 14 years:

E+H FTL33-1369/0 Liquiphant Hygienic Vibronic Tuning Fork Level Switch

FAQ of Achievers

Q:Are the Products Genuine OEM Units?

A: These items have been certified by Achievers Automation Limited to be genuine OEM Units obtained through OEM or independent third-party channels.

Q:How will you arrange shipment?

A: We can arrange shipment based on your request. We have cooperated forwader who can arrange shipment via FedEx, DHL,TNT with good price.

Q:What is the warranty of goods?

A: One-year Warranty.
