Festo NEBV-Z4WA2L-R-E-2 Solenoid Valve Connecting Cable
Festo NEBV-Z4WA2L-R-E-2 Solenoid Valve Connecting Cable
Festo NEBV-Z4WA2L-R-E-2 Solenoid Valve Connecting Cable
Festo NEBV-Z4WA2L-R-E-2 Solenoid Valve Connecting Cable
Festo NEBV-Z4WA2L-R-E-2 Solenoid Valve Connecting Cable
Festo NEBV-Z4WA2L-R-E-2 Solenoid Valve Connecting Cable
Specifications
Nominal Flow Rate (DIN 1343) :
1600 l/min
Mounting Position :
Any orientation
Packaging Details :
carton
Housing Width :
44 mm
Pressure Regulation Range :
Pressure Regulation Range
Model Number :
NEBV-Z4WA2L-R-E-2
MOQ :
1
Brand Name :
Festo
Supply Ability :
100pc
Delivery Time :
in stock
Place of Origin :
China
Type :
Pneumatic Cylinder
Payment Terms :
T/T
Seal Material :
NBR (nitrile rubber）
Description

Festo NEBV-Z4WA2L-R-E-2 Solenoid Valve Connecting Cable


Description:

Manufacturer : Festo

Product No. : NEBV-Z4WA2L-R-E-2

https://www.achievers-automation.com More Products


Reliable Industrial Component Sourcing for Enterprises

This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.

To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.


This cordset features a compact angled ZC metric screw socket that mounts directly onto solenoid valves via central M2 fastening screw, eliminating complex field wiring. A built-in yellow LED displays valve energization status for quick on-site troubleshooting. The 2-core PUR flexible cable is certified for continuous drag chain movement with strict minimum bending radius limits. IP65 ingress protection is achieved only after full valve assembly, blocking workshop dust, coolant and splashing liquid. CRC3 high corrosion resistance grade, silicone-free LABS-free construction meets VDMA24364 standards, compatible with 24VDC industrial pneumatic control circuits across automation, packaging and electronic assembly equipment.


Detail:



Parameter Item Standard Spec of Festo NEBV-Z4WA2L-R-E-2
Brand Festo
Full Model Code NEBV-Z4WA2L-R-E-2
Product Series NEBV Prefabricated Solenoid Valve Connecting Cable
Socket Pattern ZC Rectangular Metric Screw, Angled Outlet
Pin Count / Used Cores 2 pins, fully occupied (2 cores)
Fixed Cable Length 2 m
Wire Structure 2 × 0.14 mm² stranded conductor
Outer Cable Diameter 2.9 mm (Tolerance ±0.1 mm)
Nominal Operating Voltage DC 24 V
Allowed Operating Voltage Range DC 20.4 V ~ 26.4 V
Surge Withstand Capacity 2.4 kV
Polarity Protection Bipolar Reverse Polarity Protection (R suffix)
Status Indicator Integrated Yellow LED for valve energization signal
Controller End Termination E = Open Bare Wire Flying Leads
Cable Compatibility Suitable for Energy Chain Drag Chain Movement
Minimum Dynamic Bending Radius ≥29 mm
Ingress Protection Rating IP65 (Only when fully assembled to valve)
Ambient Operating Temperature -10 ℃ ~ +50 ℃
Pollution Degree (Mounted State) 3
Connector Mating Durability 50 insertion/extraction cycles
Corrosion Resistance Class CRC 3 (High Corrosion Stress)
LABS / PWIS Compliance VDMA24364-B1/B2-L (Silicone-Free)
Net Unit Weight 43 g
Certifications CE EMC Compliant, RoHS Directive Compliant
Protective Earth Conductor Not Equipped


Component Name Raw Material Grade Functional Description for NEBV-Z4WA2L-R-E-2
Socket Housing Body TPE-U (PU) Thermoplastic Elastomer Black compact molded housing, impact-resistant, integrated LED light window
Cable Outer Sheath TPE-U (PUR) Polyurethane Gray flexible sheath, oil/coolant resistant, long service life in drag chains
Internal Wire Insulation PP Polypropylene Low capacitance insulation, stable 24VDC signal transmission
Contact Pin Terminals Copper Alloy, Tin-Plated Low contact resistance, anti-oxidation for repeated mating cycles
Fastening Screw for Valve Mount Stainless Steel M2 central lock screw, anti-rust for long-term workshop operation
Built-in LED Indicator Chip Industrial Yellow SMD LED Low power consumption, clear visibility under factory lighting
Internal Protective Circuit Board FR4 Thin PCB + SMD Passive Components Realize bipolar reverse polarity blocking function
Molded Cable Strain Relief Integrated TPE-U Overmolding Eliminate wire fatigue breakage at angled cable outlet joint
Bare Wire Terminal Insulation Sleeve Heat-Shrink PP Tube Isolate exposed copper strands on controller open wire ends
